| BRAND | Burkert |
| Product | P/N: 00264840 Type: 6281 |
| Description | 2/2-way membrane valve |
| Internal code | 4195441 |
| Custom code | 84818079 |
| Technical specification | Drive type Hubanker Main valve operating principle diaphragm valve on/off switch function Fluid cable connection number 2 Nominal pressure min 0.2 bar Nominal pressure max (liquid) 16 bar Main valve nominal diameter 1 (P) (mm) 50 mm Main valve nominal diameter 1 (inch) 2 inches Kv value (water) 40 m3/h qNN value (gas) 43.000 l/min Voltage/nominal voltage 110 V Voltage Tolerance Negative\ positive 10% Voltage frequency 50/60 Hz |
Discover the superior quality and performance of the Burkert P/N: 00264840 Type: 6281 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The P/N: 00264840 Type: 6281 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of P/N: 00264840 Type: 6281 :
At RADWARD LTD , we offer the P/N: 00264840 Type: 6281 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the P/N: 00264840 Type: 6281 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Burkert products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
2/2-way solenoid valve; servo-controlled Type 0290 0290 Function A 2/2-way; Normally closed Nominal diameter 12.0 mm 12 Seal material FKM FF MS brass material GM84 line terminal G 1/2 sleeve Voltage 230 230 Volt Frequency 50 50 Hz Power 10 10 Watts Special JF01 standard cable head MA02 Electrical connection via valve outlet MT05 Direct coupling NL02 suitable for applications with oxygen (Non-metallic wetted materials are BAM-tested), Blue Label, DIS 1000020797 Pressure range 0 - 16 bar
Positioner Top Basic 70mm for Ant. 27XX Type 8694 8694 Pneumatic function E1 Single acting DN 0.6 Proximity switch 00 Without Flange FA05 interface element driving and remote Sensor to Classic or third-party drive Supply voltage E 24V DC A control current signal 4-20 mA Electr. Connection MP multipole Fluid connection S6 hose connector 6 mm and 1/4 " Operation / Config. 0 without Inputs / outputs E 1 + 1 binary input analog output Without additional function 0 Communication 0 Without Special PU02 UL listed for USA and Canada Weight: kg / pc 0.505
(Process control system with process controller Type 8802 8802 Valve type GB Globe Valve Type 2712 Control Type A positioner 8630 Control function A closed with spring force Paths / positions 2 2 way / 2-position Nominal diameter 25.0 mm 25 Seal material PTFE EE Material Stainless steel VA GM86 line terminal G 1 drive sleeve execution C PA Drive, VA-threaded socket on the Control air connection Actuator size F DM 80 mm Interface Arm./Antrieb N3 nipple thread M40 x 1.5 (standard DN 25) Function D process controller Single Input Power E single acting Displacement sensor IX way Intern Supply voltage E 24V DC F control 0-10V, 0-5V, 4-20mA, 0-20mA set Electr. PG connection terminal block with cable gland Fluid connection GV G 1/4 / VA Operation / Config. T keyboard and display internal software repeater A Analogue position feedback Additional function B binary input Communication S Serial Interface Operation A exterior)
3/2-way pneumatic valve
2/2-way solenoid valve; servo-controlled Type 6281 6281 generation EV Function A 2/2-way; Normally closed Nominal diameter 40.0 mm 40 Seal material NBR BB MS brass material GM89 line connection sleeve 2 G Coil size 6 40 mm Voltage 230 230 Volt Frequency UC direct and alternating current (AC / DC) Power consumption 09 watts 9 Special JA01 Terminal box with cable gland M20 x 1.5 (With approval PTB 00 ATEX 3119 X) + fuse (With approval PTB 01 ATEX 2064) MA02 Electrical connection via valve outlet MB05 cable outlet upwards PD53 Zulas. PTB 00 ATEX 2129X Ex m II T4 (without Kl. box) Ex em II T4 (with Kl. Box), II 2G, II 2D IP 65, Tu -30 ° C to + 60 ° C max. Surface temperature of 135 ° C, 9 W (only Individual installation)
(Process control system with process controller Type 8802 8802 Valve type GB Globe Valve Type 2712 Control Type A positioner 8630 Control function A closed with spring force Paths / positions 2 2 way / 2-position Nominal diameter 32.0 mm 32 Seal material PTFE EE Material Stainless steel VA GM87 line connection 1 1/4 inch drive socket design C PA Drive, VA-threaded socket on the Actuator size G DM 100 mm Interface Arm./Antrieb N4 nipple thread M50 x 2 (Standard DN 32) function D process controller Single Input Engine E single-acting displacement sensor IX way Intern Supply voltage E 24V DC F control 0-10V, 0-5V, 4-20mA, 0-20mA set Electr. Connection PG terminal strip with cable gland Fluid connection GV G 1/4 / VA Operation / Config. T keyboard and display internal software repeater A Analogue position feedback Additional function B binary input Communication S Serial Interface)
0262 A 12,0 EPDM MS G1/2 PN 0/6 BAR PILOT3,3/6 BAR
2/2-way control piston diaphragm valve Type 2030 2030 Control function A closed with spring force Paths / positions 2 2 way / 2-position Nominal diameter 20.0 mm 20 Sealing material AB EPDM (Food Grade) Material PVC PV Line connection KM26 adhesive connection sleeve diameter 25mm Drive Version C PA Drive, VA-threaded socket on the Control air connection Actuator size E DM 63 mm HD01 valve supplier, 8875 Pressure range 0 - 10 bar Weight: kg / pc 1.040
FIXING KIT CPL.F.PIPE 1541-4136-15Q-00
COAXIAL CABLE WITH 4 CONDUCTORS L=1.2 M COMP-435-8205 -G1-00416632
pressure transmitters Type 8323 8323 GM84 line terminal G 1/2 sleeve Material Stainless steel VA Sealing material 00 without sealing material or not specified Sensor 2P Straight gauge sensor Measuring range B is set hard Measurement function F1 L structure housing, IP65, connectors, DIN 43650, PG9 BCH voltage 10-30 Volt Frequency DC DC A output current signal 4-20 mA ML62 special measuring range from 0 to 25 bar Pressure range 0 - 25 bar Weight: kg / pc 0.200
TIP 8225 Digital Transmitter
ARMATURE PP L=1.0M COMP-475-1541 -G419-567-00
cable head
Inline Durchflusssensor
Inline flow sensor
Inline flow sensor Type sensor SE30 Line connection 0000 No Material PC PolycarbonatPPO Sealing material 00 without sealing material or not specified Sensor signal R3 uptake by Hall sensor Measuring range B is set hard Function F3 measurement pulse output L structure housing, IP65, connectors, DIN 43650, PG9 BDN voltage 12-36 Volt Frequency DC DC Z open collector output PNP / NPN Weight: kg / pc 0.220
(Inline flow sensor Type sensor SE30 Line connection 0000 No Material PC PolycarbonatPPO Sealing material 00 without sealing material or not specified Sensor signal R3 uptake by Hall sensor Measuring range B is set hard Function F3 measurement pulse output L structure housing, IP65, connectors, DIN 43650, PG9 Without voltage 000 Without frequency 00 Output 4 open collector NPN Weight: kg / pc 0.231)
Inline Flow Transmitter Type SE35 transmitter Line connection 0000 No Material 00 without housing or not specified Sealing material 00 without sealing material or not specified Sensor signal R5 uptake by inductor - Kunststoffschaufelrad A range Freely programmable Batch function F5, 2 x relay, 2 x totalizers, flow Structure C IP65, indication M20x1,5 BDN voltage 12-36 Volt Frequency DC DC Output W reversing relay Weight: kg / pc 0.600
Flow sensor module PVC 15 Type flow sensor S030 (l / min) Line connection KM25 adhesive connection sleeve diameter 20mm Material PVC PV Seal material FKM FF Sensor P5 plastic paddle wheel PVDF with permanent magnets Measuring range 0 Not specified Function 00 Without Construction 0 without Without voltage 000 Without frequency 00 Output 0 Standard Special MP29 New version DN15 Pressure range 0 - 10 bar Weight: kg / pc 0.190
Flow sensor
Flow sensor module MS Type flow sensor S030 (l / min) GM88 line terminal G 1 1/2 sleeve MS brass material Seal material FKM FF Sensor P5 plastic paddle wheel PVDF with permanent magnets measuring range 0 Unspecified Function 00 Without Construction 0 without Without voltage 000 Without frequency 00 Output 0 Standard Pressure range 0 - 16 bar
3/2 way solenoid valve
3/2-way solenoid valve, direct-acting Type 6012 6012 Function C 3/2-way; relieved in the rest position the output A Nominal diameter 01.2 1.2 mm Sealing material FB FKM NBR + Material PA polyamide Line connection 0000 No Coil size 2 20 mm Voltage 110 110 volts Frequency 50 50 Hz Power consumption 04 Watt 4 Special HA17 manual override, PA rotary manual control, rotary lever LG18 hollow screw G1 / 8 - P port Plug C. ø 6 mm Pressure range 0 - 10 bar Pressure max / gas 10 bar Weight: kg / St 0.130
2/2-way solenoid valve, direct acting Type 6013 6013 Function A 2/2-way; Normally closed Nominal diameter 02.0 mm 2 Seal material FKM FF MS brass material Line connection FB01 flange: Bürkert KL-NR.001-01-06 (32x32) Coil size 5 32 mm Voltage 048 volts 48 Frequency 50 50 Hz Power consumption 08 watts 8 Special EA60 spring 014461 Pressure range 0 - 25 bar Pressure max / gas 25 bar Weight: kg / pc 0.285
