| BRAND | Interroll |
| Product | MI-DMI AC113S-+++AUF1URFHC-1068mm |
| Internal code | 1867467 |
| Weight | 28 |
| Technical specification | Product Name Drum Motor 113S Certification UL cRUus UL Certified IP Rating 66 Shell Length 42.05 " Housing Face Width 42.91 " EL / LW / BF Between Frames 43.02 " AGL Overall Length 45.03 " Power 220 W Poles 4 Power [hp] 0.30 Torque [Nm] 26.0 Belt Pull Force 459 N Gear Ratio 23.96 Velocity at Frequency 1 [fpm] 81 Frequency 1 60 Hz Winding Phases ~ 3 High Voltage 480 V Low Voltage 0 V Finished Diameter 4.46 " Shell Shape Special Cylindrical Shell Material Stainl. Steel: 1.4301 / 304 Housing Cover Cover Material Stainl. Steel: 1.4301 / 304 Shaftcap A Feature Ø1" SC-Flat 0,72x1.01" Shaftcap B Feature Ø1" SC-Flat 0,72x1.01" Shaftcap A Material Aluminium Shaftcap B Material Aluminium Shaftcap A Diameter 1.00 " Shaftcap B Diameter 1.00 " Shaftcap A Flat Width 0.72 " Shaftcap B Flat Width 0.72 " Shaftcap A Flat Length 1.01 " Shaftcap B Flat Length 1.01 " Oil Type Food Grade Synthetic Oil Viscosity 32 Electrical Connection Side B-Side Electrical Connection Type Elbow Connector Electrical Connection Material Polyamid Power Cable Length 3.0 m Power Cable Type Non Screened; Non Halogen Free |
Discover the superior quality and performance of the Interroll MI-DMI AC113S-+++AUF1URFHC-1068mm with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The MI-DMI AC113S-+++AUF1URFHC-1068mm is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of MI-DMI AC113S-+++AUF1URFHC-1068mm :
At RADWARD LTD , we offer the MI-DMI AC113S-+++AUF1URFHC-1068mm at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the MI-DMI AC113S-+++AUF1URFHC-1068mm ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Interroll products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
