| BRAND | Wika |
| Product | 13002945 |
| Internal code | 4503611 |
| Technical specification | A-10; 0...16 bar gauge; G 1/4 A DIN EN ISO 1179-2; 0 ... 5 V, 3-wire Pressure transmitter Model A-10 (A-10) 0...16 bar gauge ; Non-linearity: 0.5% BFSL G 1/4 A DIN EN ISO 1179-2 ; Sealing: NBR 0 ... 5 V, 3-wire @ 8...30 V DC circular connector M12x1, 4-pin UB=1, 0V=3, S+=4 Permissible medium temperature: 0...+80 °C Approvals: cULus Specifications according to data sheet: PE 81.60 Details: Pressure transmitter Model A-10 |
Discover the superior quality and performance of the Wika 13002945 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 13002945 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 13002945 :
At RADWARD LTD , we offer the 13002945 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the 13002945 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Wika products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
RANGE: -1BAR ~ 1.5 BAR O/P SIGNAL: 4-2MA/O-10VDC MODEL: S-10
VACUUM TRANSMITTER
(Druckmesserumformer for general applications)
Pressure Transmitter,Output: 4 - 20mA 2 wire @ 24 V DC, Electrical Connection: DIN Plug,Accuracy:Standard, Oxygen Compatible
S-10-A-PBK-NB-ZGA4ZAZ-ZZZ TYP S-10 MESSBEREICH: 0 ... 400 PSI
Pressure transmitter for general applications Model S-10 Specifications according data sheet: PE 81.01 Power supply: DC 10 (14) ... 30 V Wetted components: Stainless steel Housing: stainless steel Output signal: 4 ... 20 mA, 2-wire Measuring range: 0 ... 400 psi Process connection: 1/4 NPT Accuracy: 0.5% of span Electrical connection: Angular connector DIN EN 175301-803 A, IP65 permissible fluid temperature: -30 ... + 100 ° C Power supply: 10 ... 30 V DC Occupancy electrical output: UB = 1, 2 = 0V
TECSIS PRESSURE SWITCH 0.2-2 BAR ATT. 1/4
S5301 -4-C1N-ND-B285GZ-ZZ DIAL-T-1AZ2ZZZZZ TYP: S 5301, NENNGROßE 5",
Bimetallic thermometer, Process Industry Series Specifications according data sheet: TM 53.01 Accuracy: Cl. 1 according to EN 13190 Housing: stainless steel Stem material: Stainless steel Type: S 5301, rotatable nominal size 5 "casing and pivotally Design of connection: 4, compression fitting sliding on stem Unit: ° C Range: 0 ° C ... 300 ° C Process connection: 1/2 NPT Stem diameter: 6 mm Installation length L1: 285 mm Window: Instrument glass
S5412 -4-C1E-ND-C160GZ-ZZ DIAL-T-1AZ1ZZZZZ
Bimetal thermometer, industrial series Specifications according data sheet: TM 54.01 / 01.15 for TV Twin Temp Accuracy: Cl. 1 according to EN 13190 Housing: stainless steel Stem material: Stainless steel Type: S 5412, rotatable size 100, housing and pivotally Design of connection: 4, compression fitting sliding on stem Unit: ° C Range: 0 ° C ... 100 ° C Process connection: 1/2 NPT Stem diameter: 8 mm Installation length L1: 160 mm Window: Instrument glass Housing: stainless steel Standard mark on the dial: * EN 13190 * Accuracy of the dial: * * CL.1
(DIAL T-1AZ1ZZZZZ Bimetal thermometer, industrial series Specifications according data sheet: TM 54.01 / 01.15 for TV Twin Temp Accuracy: Cl. 1 according to EN 13190 Housing: stainless steel Stem material: Stainless steel Type: S 5412, rotatable size 100, housing and pivotally Design of connection: 2, male nut Unit: ° C Range: 0 ° C ... 80 ° C Process connection: G 1/2 B Stem diameter: 8 mm Installation length L1: 100 mm Window: Instrument glass Housing: stainless steel Standard mark on the dial: * EN 13190 * Accuracy of the dial: * * CL.1)
Bimetallic thermometer, stainless steel Type Specifications according data sheet: TM 55.01 Housing: stainless steel Stem material: Stainless steel Type: S 5550, rotatable size 100, housing and pivotally Accuracy: Cl. 1 according to EN 13190 Design of connection: 4, compression fitting sliding on stem Unit: ° C Range: 0 ° C ... 100 ° C Process connection: 1/2 NPT Stem diameter: 6 mm Installation length L1: 317 mm Window: Instrument glass Stem material: Stainless steel 1.4571 IP 65 Manufacturers Logo: * * WIKA
Bimetallic thermometer, stainless steel Type Specifications according data sheet: TM 55.01 Housing: stainless steel Stem material: Stainless steel Type: S 5550, rotatable size 100, housing and pivotally Accuracy: Cl. 1 according to EN 13190 Design of connection: 4, compression fitting sliding on stem Unit: ° C Range: 0 ° C ... 160 ° C Process connection: 1/2 NPT Stem diameter: 6 mm Installation length L1: 392 mm Window: Instrument glass Stem material: Stainless steel 1.4571 IP 65 Manufacturers Logo: * * WIKA
Bimetallic thermometer, stainless steel Type Specifications according data sheet: TM 55.01 Housing: stainless steel Stem material: Stainless steel Type: S 5550, rotatable size 100, housing and pivotally Accuracy: Cl. 1 according to EN 13190 Design of connection: 4, compression fitting sliding on stem Unit: ° C Range: 0 ° C ... 160 ° C Process connection: 1/2 NPT Stem diameter: 6 mm Installation length L1: 402 mm Window: Instrument glass Stem material: Stainless steel 1.4571 IP 65 Manufacturers Logo: * * WIKA
Bimetallic thermometer, chemical version Specifications according data sheet: TM 55.01 Housing: stainless steel Stem material: Stainless steel Type: S 5550, rotatable size 100, housing and pivotally Accuracy: Cl. 1 according to EN 13190 Design of connection: 4, compression fitting sliding on stem Unit: ° C Display range: -20 ° C ... + 100 ° C Process connection: 1/2 NPT Stem diameter: 6 mm Installation length L1: 160 mm Window: Laminated safety glass Stem material: Stainless steel 1.4571 IP 65 Manufacturers Logo: * * WIKA
claud BIMETAL THERMOMETER, MODEL: S550, NOMINAL SIZE 100, ADJUSTABLE STEM AND DIAL, ACCURACY CLAASS 1 PER EN 13190, SS
(Bimetallic thermometer, stainless steel Type Specifications according data sheet: TM 55.01 Housing: stainless steel Stem material: Stainless steel Type: S 5550, rotatable size 100, housing and pivotally Accuracy: Cl. 1 according to EN 13190 Design of connection: 2, male nut Unit: ° C Range: 0 ° C ... 100 ° C Process connection: G 1/2 B Stem diameter: 6 mm Installation length L1: 190 mm Window: Instrument glass Stem material: Stainless steel 1.4571 IP 65 Manufacturers Logo: * * WIKA)
Diaphragm Seal;Version: Standard; Filling Fluid: Silicone Oil; Coupling: Dist. 3M;AISI 316L diaphragm;AISI 316 process connection;Flange size: 6" ANSI 150 RF;Armored capillary: 3 mt
thermoregulator
MODEL : GA10 INCLUDED DATA ACQUISITION BOARDS , SF6 MOISTURE SENSOR IN CARTRIDGE SF6 PERCENTAGE SENSOR IN CARTRIDGE SO2 SENSOR IN CARTRIDGE CALIBRATION CERTIFICAT AND STD. ACCESSORIES INTERFACE : BLUETOOTH (FRAX-101 ONLY) AND USB WARRANTY 2 YEARS
SN: P074202
membrane
temperature transmitter
(OEM screw-TF35 Measuring range: -50 ... + 250 ° C Measuring element: 1xPt100 / 2-wire connection Tolerance: Class B, DIN EN 60751 Thermowell material: Brass Protective tube diameter [F1 o F2.]: 7.5 mm Process connection [E]: thread G1 / 4B Installation length [U1]: 28 mm Electrical connection: connector AMP Junior Power Timer; Marking: WIKA Packing: plastic bag Data Sheet: TF35 - TE67.10 Customs tariff number: 90251920)
Range: 0 °C to 200 °C, Length 400mm, Diameter 8mm.
Range: 0 °C to 200 °C, Length 400mm, Diameter 8mm.
Range: 0 °C to 100 °C, Length 240mm, Diameter 8mm
Range: 0 °C to 100 °C, Length 240mm, Diameter 8mm
