BRAND | Warex |
Product | 137938 / 2010 / WX2000 / Type DKZ110 DN 250 |
Description | butterfly valve |
Internal code | 5061167 |
Custom code | 84818085 |
Technical specification | Basis: Preliminary contract 137938/2010 for medium: bulk material, fluid group 2 Property: free-flowing, chemically neutral, not prone to baking Work Pressure: Vacuum max. allowable Operating overpressure: 1.0 bar (Ps) MAWP (Note: MAWP = Ausl. -Pressure) Operating temperature: 0 °C... + 60 °C (Ts) MAWT Surround. -Temperature: 0 °C... + 45 °C (Ta) Explosion protection: no requirement evaluation of butterfly valves in accordance with DGRL 2014/68/EU, Diagram 7, certified module A2. The valves are not subject to conformity assessment. Test pressure: design pressure x 1.1 bar on density Butterfly valve, type DKZ110 DN 250 Construction length 68 mm for clamping between flanges in accordance with EN 1092, PN 10 Silumin housing stainless steel flap disc 1.4408 1.4057 or higher grade stainless steel shafts Shaft sealing with O-rings Brass shaft bearing - socket White NBR sealing collar firmly glued in the housing further attachments: pneumatic rotary actuator AT 220 DR double-acting required control pressure 6.0 bar |
Discover the superior quality and performance of the Warex 137938 / 2010 / WX2000 / Type DKZ110 DN 250 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 137938 / 2010 / WX2000 / Type DKZ110 DN 250 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 137938 / 2010 / WX2000 / Type DKZ110 DN 250 :
At RADWARD LTD , we offer the 137938 / 2010 / WX2000 / Type DKZ110 DN 250 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the 137938 / 2010 / WX2000 / Type DKZ110 DN 250 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Warex products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
