BRAND | Burkert |
Product | 20019233 |
Internal code | 5033279 |
Technical specification | Process control system with positioner 8802-YG-L-A-50,0SS-VA-SODI-N-0-E-I-L-0-0 Type 8802 8802 Valve type YG angle seat valve type 2300 Control type L Positioner basic 8694 Control function A Closed with spring force Ways/positions 2 2 ways/2 positions Nominal size 50.0 50 mm SS stainless steel sealing material Material VA stainless steel SODI welding 50.8 x 1.65 cable connection according to ASME BPE, DIN 11866 series C (can be used for BS4825-1) Line connection 1 0000 not available Drive Type G Element Design Drive Drive size N DM 90 mm Arm interface. /Drive N6 nipple thread M70 x 2 (standard DN 50) Control air connection FA03 Interface element control and remote sensor to element drive Flange diagram FA03 Interface element control and remote sensor to element drive Design 0 without Function 0 Not specified Pneumatic function E1 single-acting DN 0.6 Drive type 0 without valves Position sensor 00 Without Supply voltage E 24V DC Control A current signal 4-20mA Electr. KD cable outlet connection Fluidic connection GW G 1/8/VA Operation/Config. 0 without Proximity sensor 00 Without Software sensor I 1 binary input + 1 analog output Additional function 0 Without Communication L Service BÜS Attachment 0000 without Service 0 Not available VB1 00 valve block not equipped Control function VB1 0 Not specified VB2 00 valve block not equipped Control function VB2 0 Not specified Approval system 0 Without approval Accessories 0 Without AF93 Case OD Tubing long Assembly/delivery variant NK51 Packaged seal included Approval component PL01 suitable for use with food, not in contact with media metallic materials comply with EC Regulation 1935/2004 PU02 UL component approval listed for USA and Canada cULus |
Discover the superior quality and performance of the Burkert 20019233 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 20019233 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 20019233 :
At RADWARD LTD , we offer the 20019233 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the 20019233 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Burkert products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
