| BRAND | Nuova Fima |
| Product | 2151AG---.ACEY.43M.SQ2.MII.M3D.S26.C.CH1.TCM |
| Description | DIFFERENTIAL PRESSURE SWITCH INDICATOR RANGE 0 TO 1KG/CM2 ND160 |
| Internal code | 5035272 |
| Technical specification | Model: MD15 6" (150 mm) Case Diameter.Bottom Connection Range 0...1 Kg/CM2 1/2" NPT Male Process Connection S.S. AISI 316l Double Diaphragm For Ranges Up To 160 mbar; AISI 316l/duratherm For Ranges Equal Or Upper 250 mbar Aluminium Dial, White Background With Black Markings And Figures M3D Electric Contact Type MPM Junction Box S.S. Case And Bayonet Ring Wall Mounting With Back Flange Black Aluminium Micrometric Adjustable Pointer S.S. Precision Movement Accuracy ±1,6% Weaterproof Key IP55 Makrolon Transparent Hood |
Discover the superior quality and performance of the Nuova Fima 2151AG---.ACEY.43M.SQ2.MII.M3D.S26.C.CH1.TCM with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 2151AG---.ACEY.43M.SQ2.MII.M3D.S26.C.CH1.TCM is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 2151AG---.ACEY.43M.SQ2.MII.M3D.S26.C.CH1.TCM :
At RADWARD LTD , we offer the 2151AG---.ACEY.43M.SQ2.MII.M3D.S26.C.CH1.TCM at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the 2151AG---.ACEY.43M.SQ2.MII.M3D.S26.C.CH1.TCM ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Nuova Fima products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Pressure gauge Type: 1.18.2.A.G.41M Execution: all st.st. bourdon tube pressure gauge fillable Mounting: direct diameter: DN 150 Connection: 1/2" BSP male bottom Range: 0- 250 bar Case material: bayonet-lock case in st.st. AISI 304 window material: glass accuracy: Kl.1,0 Statistische Warennummer: 90262040
Digital Portable Manometer Series 2000 Type 2028P (Extended Version) For Pressure, Vacuum and Differential pressure Battery operated Hand-Held with LCD-Display Range: 0-1 bar (max. Overrange 2 bar) Display range: 0,0-199,9 mbar and 0-1000 mbar Accuracy: 0,15% rdg + 0,15% FSO +1digit Switchable to Pa, inH2O, mH2O, inHg, mHG, PSI (Display range acc. to data-sheet) Pressure ports: 2 x tube connection for tube 4 mm inner diam. / 6 mm outer diam. Display Backlight (switchable) Zero setting by keypress HOLD-Function Automatic Switch of the Display resolution can be deactivated MAX/MIN Memory Number of pushbuttoms: 8 Protection: IP 67 (with connected tubes) Battery Type: 2 x AA, 1,5 V (not included in delivery)
Pressure gauge Type: 01.20.3.A.G.ABFD.41M.L02 Execution: All st.st. bourdon tube pressure gauge, SOLID FRONT, Glycerine filled Mounting: direct Diameter: DN 150 Connection: 1/2" BSP male in st.st. AISI 316 L Range: 0-15 psi Case material: bayonet-lock case in st.st. AISI 304 Window material: safety glass Accuracy: Kl. 1.0 with adjustable pointer
pressure switch
00020 201071825 GAUGE:PRESS;0-10KG/CM2,1/8IN,NPT,2-1/2IN GAUGE: PRESSURE RANGE: 0-10 KILOGRAM PER SQUARE CENTIMETER CONNECTION SIZE: 1/8 IN CONNECTION: NATIONAL PIPE THREAD FACE SIZE: 2-1/2 IN CONNECTION LOCATION: LOWER MANUFACTURER: NUOVA FIMA MODEL NUMBER: 52240251060000 *PHOTOS ATTACHED* 00030 201090588 TRANSDUCER:ELECTRO PNEUMATIC,4 TO 20MA,%
TEMPERATURE GAUGE, RANGE 0-160C, APPLICABLE SERIAL NO 2758/02
TEMPERATURE GAUGE, RANGE 0-200C, APPLICABLE SERIAL NO 2758/06
thermostat
(Test and conformity of 3.1 NUOVA FIM)
DDM-DM-D-DIVERS 02.16.1.A.G.0/600 mbar.43M.C.S31.R10
Statistische Warennummer: 90262040 Differential pressure gauge Type: 02.16.1.A.G.0/600 mbar.43M.C.S31.R10 Execution: with double diaphragm Mounting:direct or with back flange diameter: DN 150 Lower Connections: 1/2" NPT male in st.st. AISI 316L Range: 0- 600 mbar static pressure: max. 100 bar Case material: bayonet-lock case in st.st. AISI 304 window material: glass case filling: glycerine 2" Stackes bracket accuracy: Kl. 2,5 %
Commodity Code: 90268020 Type Pressure transmitters: 08.S18 NUOVA FIMA Code: 08.S18-0 / 40 bar-23M-1 Measurement range: 4-20 mA 2 wire Power: 0-40 bar output 8-30 VDC accuracy: 0 , 5% FSO IEC 60770 Process connection .: 1/4 NPT male thread Electrical connection:. connector DIN 43650 IP 65
DMU-S-D-001009 08.S18 08 / S18 AAFE = 0-16 BAR 23M 1 = OUTPUT: 4...20 MA- 2 WIRES , SUPPLY: 8...30
Pressure sensor Execution: pressure sensor with ceramic cell
Pressure sensor Type: 08.S18 Execution: pressure sensor with ceramic cell Accuracy: 0,5% F.S.V acc. to IEC 60770-Limit point Electrical connection: Male and female plug DIN 43650 Specification Code acc. to Data-sheet 08 = Electronics S18 = Pressure transmitter 0-600 bar = range 43M = process connection: 1/2 NPT male 10E = output: 4-20 mA, 2 wire / supply: 10..30 VDC Please check the process connection and output. It was not specified in the inquiry.
Statistische Warennummer: 90262040 Pressure transmitter with local readout for homogenizer Type: 08.MOM.3.A.E.AAFZ (0...400 bar).422.1. Filling liquid: dielectric oil Mounting: direct, bottom connection Dial diameter: 100 mm Process connection: SA422 Range: 0-400 bar case in st.st. AISI 304 glass window Output: 4-20 mA Power Supply: 10...30Vcc with logo "NUOVA FIMA" and "LR"
Pressure gauge Type: 1.20.3.A.E.41M. Execution: all st.st. bourdon tube pressure gauge Solid front execution, glycerine filled Mounting:direct dial diameter: DN 100 Range: 0-16 bar Case material: bayonet-lock case in st.st. AISI 304 window material: safety glass accuracy: Kl. 1,0 with diaphragm seal MGS 9/2B 4.2B0.9.9.43F.41F.BAI diaphragm in Hastelloy C276 process connecion in Hastelloy C276 process connection: 1/2" NPT female
(Pressure transmitter with local readout for homogenizer Mounting: direct, bottom connection Dial diameter: 100 mm Process connection: SA167 Range: 0-600 bar case in st.st. AISI 304 glass window Output: 4-20 mA Power Supply: 10...30Vcc with calibration certificate (C01))
CAMERA
Statistische Warennummer: 90262040 Pressure gauge Type: 01.27.1.A.I Execution: Laboratory bourdon tube test gauge Mounting: direct Diameter: DN 250 (10") Connection: 1/2 NPT male bottom in st.st. AISI 316 Range: 0-40 bar Case material: Aluminium, black coated External zero-adjustment High precision movement mounted on ball bearing Dial: Anti-parallax mirror Pointer: balanced, antiparallax knife-edge micrometer, adjustable Window material: Plexiglas Accuracy: Kl. 0,1 Specials: factory test certificat, traceable to international Standard
range 0-250 bar
(version "all stainless steel": DN 63) 1.18.3.DC0/16 BAR.21M
(Pressure gauge Type: 01.M2.3-D-E-0/400 bar-41M-04D.BM2.E Execution: all st.st. bourdon tube pressure gauge MCE18/3/E oil filled with double electric contact Mounting: with front flange diameter: DN 100 Connection: 1/2" BSP back in st.st. AISI 316L Range: 0-400 bar Case material: bayonet-lock case in st.st. AISI 304 window material: Plexiglas contacts: First contact opening, second contact opening on rising pressure, magnetic snap action)
Over pressure protection MP 4/8A in st.st. AISI 316 5.48A.5.41M.41F setting: 3....15 psi process connection : 1/2" BSP male gauge connection: 1/2" BSP female
MGS18 1.18.2.A.E-.AAFB.43M.C40.T32
pressure gauge
1.18.3.A.E.---.DAE7.41M.KCS ALL ST. ST. PRESSURE GAUGE, MODEL MGS18. 4" (100 MM) CASE DIAMETER. BOTTOM CONNECTION., RANGE 0...6 BAR/PSI, 1/2" BSP MALE PROCESS CONNECTION, ALUMINIUM DIAL, WHITE BACKGROUND WITH BLACK MARKINGS AND FIGURES, ST. ST. CASE AND BAYONET RING, DIRECT MOUNTING, ST. ST. PRECISION MOVEMENT, BLACK ALUMINIUM POINTER, ACCURACY ±1,0%, GLYCERINE FILLING, IP67 PROTECTION DEGREE, TEMPERED GLASS WINDOW, ST.ST. RESTRICTOR, MOUNTING WITH DIAPHRAGM SEAL
