| BRAND | Regloplas |
| Product | Type: 300LD/20/FM65/1K-RT100 |
| Description | temperature control unit |
| Internal code | 4317096 |
| Technical specification | Article number G-001399 consisting of: * G-300LD-0002 300LD/20/FM65/1K-RT100 2-circuit device Semi-open system Flow temperature max. 300°C Heat transfer oil Capacity 24.0 l Expansion space 20.0 l Heating capacity 20 kW Cooling capacity 160 kW Cooling type indirect cooling at flow temperature 280°C at a cooling water temperature of 20°C at a flow rate per circuit 20 l/min FM65 pump type magnetic drive pump Maximum flow rate 90 l/min Pressure max. 10 bar Power consumption 2.8 kW System pressure max. Semi-open system Flow pressure max. pump pressure RT100 control Measurement type Pt100 ports Forward/backflow G ¾” IG G ¾” cooling water network Total power consumption approx. 70.8 A (at 400V/50Hz) Net water pressure min. 2-6 bar Protection class IP54 Ambient temperature max. 40 °C Dimensions W/H/D 432/1356/1474 mm Weight approx. 246 kg Colour grey, RAL 9006/7016 Continuous sound pressure level <70 dB (A) standard equipment - PID controller with high accuracy - SSR for wear-free switching of the heating - USB data logger for process logging as a CSV file - Dirt filter in the water supply connection - Dirt filter in the system return - lockable transport wheels - internal bypass for pump protection - Analog display for system and flow pressure - Dry run protection/level monitoring - filling nozzle for manual filling - Stainless steel expansion tank - Two-stage level monitoring - without connection cable, without plug *O-300LD-MR0036 Voltage 440-480V/60Hz according to UL/CSA instead of 400V/50Hz Execution: UL valve plug UL valve coils CE transformer UL safety thermostat UL clamps CE heater CE controller CC type fuse AWG wiring CE type plate EU Declaration of Conformity UL relay UL contactor UL filling pump CE pump without test certificate, subject to technical changes * O-300LD-MP2020 suction off the heat transfer medium, and Leak stop mode including automatic direction correction * O-300LD-MP2113 Flow measurement F351 - outside per circle: Temperature range up to 350°C Heat transfer oil Measurement range 2l/min — 50 l/min Measuring type paddle wheel Nominal size/connection 12 mm/G ¾” External mounting position, rear of the device Display via RT100/RT200 control system Limit value setting via RT100/RT200 control system Description permanent flow monitoring |
Discover the superior quality and performance of the Regloplas Type: 300LD/20/FM65/1K-RT100 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The Type: 300LD/20/FM65/1K-RT100 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of Type: 300LD/20/FM65/1K-RT100 :
At RADWARD LTD , we offer the Type: 300LD/20/FM65/1K-RT100 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the Type: 300LD/20/FM65/1K-RT100 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Regloplas products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
