| BRAND | Nuova Fima |
| Product | 340---.AAFB.D.1.41M.2D2 |
| Internal code | 3287874 |
| Weight | 3 |
| Technical specification | EEXD DIAPHRAGM PRESSURE SWITCH, 0425 ATEX 2634 APPROVAL, MODEL 3.40. ALUMINIUM ALLOY BODY AND COVER, PROTECTION DEGREE IP65. STAINLESS STEEL AISI316 PROCESS CONNECTION. FINE THREAD INNER ADJUSTING SCREW. ELECTRIC CONNECTION DIRECT ON MICROSWITCH RANGE 0...10 BAR N°2 FIXED DIFFER. SCREW TERMINAL, SPDT MICRO, 15A-250VAC/0,1A-24VDC 1/2" BSP TAPERED FEMALE ISO7-1 ELECTRICAL CONNECTION 1/2" BSP MALE PROCESS CONNECTION MARKING - II 2 GD Ex db IIC T6 Ex tb IIIC T85°C (TF2 rev.1) ST. ST. AISI 316 DIAPHRAGM |
Discover the superior quality and performance of the Nuova Fima 340---.AAFB.D.1.41M.2D2 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 340---.AAFB.D.1.41M.2D2 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 340---.AAFB.D.1.41M.2D2 :
At RADWARD LTD , we offer the 340---.AAFB.D.1.41M.2D2 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the 340---.AAFB.D.1.41M.2D2 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Nuova Fima products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Pressure gauge Type: 01.18.1.A.G.43M.0/3000 psi Execution: all st.st. bourdon tube pressure gauge Mounting: direct Diameter: DN 150 (6") Connection: 1/2" NPT male Range: 0-3000 psi Case material: bayonet-lock case in st.st. AISI 304 Window material: tempered glass Accuracy: Kl. 1.0
(DRUSCHA-D-DIVERS,Pressure switch Type 03.30.AAFV.A.1.23F.,1 microswitch Type A, single standard,setting range: 6-250 bar,cable exit: 1/2" BSP female UNI 6125,process connection: 1/4" NPT female)
DRUMI-D-DIVERS Execution: all st.st. bourdon tube pressure gauge MGS 18/2 Mounting: direct diameter: DN 100 Range: 0- 100 bar (AAFP) Case material: bayonet-lock case in st.st. AISI 304 window material: glass with vacuum stop (F01) with diaphragm seal 04.2B0.5.4.43M.41F.D.BAI MGS 9/2B0 diaphragm seal in AISI 316L process connection: 1/2" NPT male in st.st. AISI 316L direct mounting stainless steel bolts and nuts Mnfr: NUOVA FIMA
Execution: all st.st. pressure gauge, MGS 20/A "SOLID FRONT" safety execution Mounting: direct Diameter: DN 100 Connection: 1/2" NPT male Range: 0-100 kg/cm² Case material: Bayonet-lock case in st.st. Window material: Safety glass Accuracy: 1,0
Execution: all st.st. pressure gauge, MGS 20/A "SOLID FRONT" safety execution Mounting: direct Diameter: DN 100 Connection: M20 X 1,5 Range: 0- 0,6 kg/cm2 Case material: Bayonet-lock case in st.st. Window material: Safety glass Accuracy: 1,0
1.20.3.A.G.-ABFD.41M.L02 0-10 PSIG
Pressure Gauge 6" Dial size. Range 0-10 PSIG, 1/2" Bottom Con.
Pressure gauge Type: 02.42.1.A.E.0/250mbar.41M Execution: all st.st. diaphragm pressure gauge Mounting: direct Diameter: DN 100 Connection: 1/2 NPT male bottom in st.st. AISI 316 Range: 0-250 mbar Case material: bayonet-lock case in st.st. AISI 304 Window material: glass Accuracy: Kl. 1.6
Commodity code: 90262040 Glycerine Bourdon tube pressure gauges according to EN 837-1 1.18.3.A.G.0 / 6 bar.41M.T32 Robust CHEMIE design, all stainless steel Case diameter: NG 160 Connection G 1/2 B stainless steel bottom Measuring range: 0 - 6 bar (pitch: 0.05 bar) All wetted parts in stainless steel AISI 316 Bayonet ring case stainless steel Housing with BLOW OUT (pressure relief) Cover plate of safety glass Protection: IP 67 Grade 1.0 NUOVA FIMA
Pressure gauge
Pressure gauge Type: 01.18.3.A.E.43M.Execution: all st.st. bourdon tube pressure gaugewith glycerine filling
183-100-D-DIVERS 01.18.3.D.E.43M.B
Statistische Warennummer: 90262040 Pressure gauge Type: 01.18.3.D.E.43M.B Execution: all st.st. bourdon tube pressure gauge, Glycerine filled Mounting: panel with bracket Diameter: DN 100 Connection: 1/2 NPT back in st.st.AISI 316L Range: -1 / +5 bar Case material: bayonet-lock case in st.st. AISI 304 Window material: glass Accuracy: Kl. 1.0 Protection: IP 67
Pressure gauge Type: 01.18.2.A.E.43M.P01 Execution: all st.st. bourdon tube pressure gauge, MGS18/2/A/E fillable with silicone oil Mounting: direct Diameter: DN 100 Connection: 1/2" NPT male bottom Range: 0-250 bar Case material: bayonet-lock case in st.st. AISI 304 Window material: glass Accuracy: 1,0
Pressure gauge Type: 01.18.2.D.E.43M.P01 Execution: all st.st. bourdon tube pressure gauge, MGS18/2/D/E fillable with silicone oil Mounting: direct Diameter: DN 100 Connection: 1/2" NPT male back Range: 0-250 bar Case material: bayonet-lock case in st.st. AISI 304 Window material: glass Accuracy: 1,0
Pressure gauge Type: 1.18.2.A.G.41M Execution: all st.st. bourdon tube pressure gauge fillable Mounting: direct diameter: DN 150 Connection: 1/2" BSP male bottom Range: 0-16 bar Case material: bayonet-lock case in st.st. AISI 304 window material: glass accuracy: Kl.1,0 , Statistische Warennummer: 90262040
Digital Portable Manometer Series 2000 Type 2028P (Extended Version) For Pressure, Vacuum and Differential pressure Battery operated Hand-Held with LCD-Display Range: 0-1 bar (max. Overrange 2 bar) Display range: 0,0-199,9 mbar and 0-1000 mbar Accuracy: 0,15% rdg + 0,15% FSO +1digit Switchable to Pa, inH2O, mH2O, inHg, mHG, PSI (Display range acc. to data-sheet) Pressure ports: 2 x tube connection for tube 4 mm inner diam. / 6 mm outer diam. Display Backlight (switchable) Zero setting by keypress HOLD-Function Automatic Switch of the Display resolution can be deactivated MAX/MIN Memory Number of pushbuttoms: 8 Protection: IP 67 (with connected tubes) Battery Type: 2 x AA, 1,5 V (not included in delivery)
