BRAND | Scherzinger |
Product | 351 FB/M1,5/GN/I33 |
Description | pump |
Internal code | 4428327 |
Custom code | 84136039 |
Technical specification | 200965 Rotation direction: right (cw), pump shaft view Slip volume: 20.92 cm3/rev Safety valve: 11-20 bar, set to 18 bar Connections: DIN ISO 228, G 3/4" Inlet pump inlet pressure ፦0.7... 0.5 bar Operating temperature range ፦15 to 160°C Gears with increased backlash for better particle compatibility Housing material: EN GJL 250 Gear material: EN 11smN30 Shafts: EN 11smN30 plain bearings: EN GJL 250 stat.gasketsL: FKM Shaft seal: double radial shaft seal FKM three-phase motor Engine size: IEC90L Engine bit: IMB34 flange diameter: 160 mm Nominal power: 1.5/1.8 kW Nominal Speed: 1.445/1734 1/min voltage 230/Y 400V 50Hz 3~ 265/Y 460 V, 60 Hz, 3~ clemenbox:right |
Discover the superior quality and performance of the Scherzinger 351 FB/M1,5/GN/I33 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 351 FB/M1,5/GN/I33 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 351 FB/M1,5/GN/I33 :
At RADWARD LTD , we offer the 351 FB/M1,5/GN/I33 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the 351 FB/M1,5/GN/I33 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Scherzinger products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
CASING
BUSHING
SCREW
SCREW
SCREW
SEAL
SUPPORT RING
SPRING
CUP SPRING
ROTARY SHAFT SEAL
O-RING
O-RING
O-RING
PIN
Needle bearing
Needle bearing
Ball Bearing
Ball Bearing
Ball Bearing
Key
Key
