| BRAND | Monarch Instrument |
| Product | 6220-033 |
| Description | Strobe Kit |
| Internal code | 575287 |
| Weight | 1 |
| Technical specification | vbx Vibration Strobe Kit 115/230V without interface cable Vibration stroboscope - 30-50,000 BPM, with PSC-PBXu power supply/ charger, 115/230 Vac, spare bulb and CA-4046-6 Accelerometer cable in plastic protective case Flash ranges: 30-50,000 BPM (0.5-830 Hz) Accuracy: ± 0.002% of setting, digital adjustment knob Resolution: 0.01 to 1.0 BPM (selectable) Supply: NiMH batteries (approx. 2 hours) and power supply (continuous operation) Phase delay: 01 to 359.9 degrees Time delay: 0.01 to 1000 msec., slow motion: 0-200 vUpm Flash energy: 230 mJoules up to 3450 BPM Speedometer mode: 5-250,000 RPM from external sensor External input: pulse -0.5 μsec. min., TTL to 24V max Trigger output: 3.3V TTL compatible 40 μsec. Pulse Weight: 0.8 kg |
Discover the superior quality and performance of the Monarch Instrument 6220-033 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 6220-033 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 6220-033 :
At RADWARD LTD , we offer the 6220-033 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the 6220-033 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Monarch Instrument products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Nozzle
Nozzle
Nozzle
Nozzle
Nozzle
Nozzle
Nozzle
Nozzle
Optional PM Software (CD)
Speed sensor ROS-W
Speed sensor ROS-P Optical speed sensor stainless steel casing with 2.5 m long cable and 1/8 "phono plug (3.5mm) Range from 1 to 250,000 RPM, distance: 1m to 45 ° Supply: 3-15VDC, @ 40 mA, output: negative pulses (+ V) after 0, pulse height as applied voltage Green LED for target recognition Ambient temperature: -10 ° C to 70 ° C Dimensions: 73 (L) x16mm (diameter) incl. fastening angle (aluminum) with (2) and lock nuts 30 cm reflection stripes
Speed sensor ROS-P-25 Optical speed sensor with 7.5m cable length and 1/8 " Phono plug (3.5mm) Range from 1 to 250,000 RPM, distance: 1m to 45 ° Supply: 3-15VDC, @ 40 mA, output: negative pulses (+ V) after 0, pulse height as applied voltage Green LED for target recognition Stainless steel housing M16 Dimensions: 73 (L) x16mm (diameter) incl. fastening angle (aluminum) with (2) and lock nuts 30 cm reflection stripes
Speed sensor
Palm StrobeX Pak 115/230 Hand stroboscope with digital display Flash rate variable via joystick button 5.5 cm reflector diameter Flash rate: 100-12500 BPM replaceable battery cartridges incl. charger, second battery cartridge, holster, Description
Nova strobe bax 230 Strobes base with digital display Interchangeable xenon bulb Adjustable Strike rate: 30 to 10,000 BPM Supply voltage 230V AC 50/60 Hz
Tachometer
Remote Optical LED Sensor
Vibration meter
6400-012 / EXAMINER 1000 Vibration Meter
Vibration meter and electronic stethoscopes with OnTime GP software
(Optical speed sensor Stainless steel casing with 2.5 m long cable on a 3-core strand Range from 1 to 250,000 RPM, distance: 4 cm to 1 m, 45 ° Visible red LED beam Supply: 3-15VDC, @ 40 mA, output: negative pulses (+ V) after 0, pulse height as applied voltage Green LED for target recognition Ambient temperature: -10 to 70 ° C Dimensions: 73 (L) x16mm (diameter) incl. mounting bracket, 2 x locknuts, description, and 30 cm reflection stripes)
strobe dbx Stroboscope with mains supply, 30-10000 flashes per minute, Find by fast dynamic knob backlit display for flashes / min., flashes / sec., Speedometer, battery performance. 2 function keys for doubling / halving flash frequency. Supply: 115/230 VAC, Device including flash
NOVSDAXK KOMPLETTSET STROBOSKOP DAX
Stroboscope with network operation, 30-20000 flashes per minute, Fast Find by dynamic knob backlit display for flashes / min., flashes / sec., Tachometer, battery power. 6 function keys 6 primaries, phase offset and frequency division and -vervielfachung. Supply: 230 VAC Unit incl. Flash, flash tube and plastic case
LED stroboscope DBL Stroboscope with battery operation, 30-500000 flashes per minute, Brightness: 3,000 LUX at 6000 flashes / minute, fast fi nd by dynamic knob, backlit display for flashes / min., flashes / sec., Tachometer, Chargers el erformance. gation buttons 12 functi ung 6 primaries, phase offset and frequency sub- and -vervielf attening. Ext. Trigger: TTL input (24 VDC max.), Output: 3.3 VDC. Operation: 8 to 10 typical at 1,800 flashes / minute Std.. Device i ncl. Charger
PALM Strobe x single device Battery, 100 to 12,500 flashes per minute, Fast Find by multifunction knob backlit display for flashes / min., flashes / sec., Tachometer, battery power. 2 function keys 8 primaries, frequency division and -vervielfachung the multifunction button. Flash output: 145mJ / flash charge time: 2-3 hours. Operation: 60 min. Unit incl. Flash tube, 1 battery and charger
PALM strobe x Deluxe Kit Battery operation, 100-12500 flashes per minute, Find it fast through the multifunction knob backlit display for flashes / min., flashes / sec., Speedometer, battery performance. 2 function keys with 8 presets, frequency division and multiplication on multi-function button. Flash output: 145mJ/Blitz Charging time: 2-3 hours, Operating: 60 min Device including flash tube, 1 spare battery, charger and carry case
(Remote Optical Sensor with 25 ft. cable, 12 inches of Reflective tape and mounting bracket.)
Nova-Strobe PBL
Phaser-Strobe
