BRAND | Thermokon |
Product | 626347 |
Internal code | 4890991 |
Custom code | 90258040 |
Technical specification | FTK+ 140 VV Duct sensor temperature, humidity — 0.. 5 V, 0.. 10 V Output voltage: 2x 0.. 10 V or 0.. 5 V, adjustable via jumper, min. load 10 kO Operating temperature range: -20.. +70 °C, temperature accuracy: ±0.3 K (typ. at 21 °C) in Standard measurement range, potentiometer for offset adjustment Humidity measurement range: 0..100% rH without condensation, 0.. 85 kJ/kg enthalpy, 0.. 50 | 0.. 80 g/m³ absolute Humidity, 0.. +50 | -20.. +80 °C dew point, adjustable on the transmitter Humidity accuracy: ± 2% between 10..90% rH (typ. at 21 °C), potentiometer for offset adjustment Power supply: 15.. 24 V = (± 10%) SELV, 24 V ~ (± 10%) SELV Connection: removable Flextherm M20 cable entry for cables with Ø=4.5.. 9 mm, detachable plug-in terminal, max. 2.5 mm² Material in contact with media: sensor tube, PA6, with stainless steel wire mesh filter, black, Ø=19.5 mm, Installation length: 140 mm, housing: USE-S, impact and shatterproof housing with hinged cover, PC, Colour: pure white, protection class: IP65 Box contents: including mounting flange, including mounting kit (screws and accessories) Notes: flow rate max. 12 m/s |
Discover the superior quality and performance of the Thermokon 626347 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 626347 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 626347 :
At RADWARD LTD , we offer the 626347 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the 626347 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Thermokon products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
