BRAND | Faggiolati |
Product | AJ30G411R55MA |
Internal code | 4249230 |
Technical specification | CONSTRUCTION DATA Impeller type Centrifuge radial Suction (mm) DN 80 Cooling By surrounding fluid Motor type M411T-7,1-400/50YY-IE3 - (Watertight, suitable for VFD) Mechanical prot. Degree IP 68 Rated motor power (kW) 7,1 Rated current (A) 13,5 Starting type Direct - Star/Delta Starting Supply 3ph 400/690V-50Hz Nominal speed (rpm) 1436 Winding insulation Class H Duty service S1 Continuous Electric cable Neoprene submersible length 20 m. Shaft seal Double Mechanical Liquid max. temperature (°C) < 40 Pump protection Motor Thermal Protections - Leakage Sensor in oil chamber Surface painting Epoxy painting MATERIALS Diffuser Stainless steel AISI 304 Shaft Stainless Steel AISI 431 Impeller Stainless Steel AISI 316L Upper seal Ceramic/Graphite Lower seal Silicon Carbide/Silicon Carbide Screws A4 Class AISI 316 O-Rings Nitrile MATERIALS Diffuser Stainless steel AISI 304 Shaft Stainless Steel AISI 431 Impeller Stainless Steel AISI 316L Upper seal Ceramic/Graphite Lower seal Silicon Carbide/Silicon Carbide Screws A4 Class AISI 316 O-Rings Nitrile Ball bearings Ball Bearings, life lubricated Motor Casing Cast Iron EN-GJL-250 Suction Chamber Stainless steel AISI 304 |
Discover the superior quality and performance of the Faggiolati AJ30G411R55MA with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The AJ30G411R55MA is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of AJ30G411R55MA :
At RADWARD LTD , we offer the AJ30G411R55MA at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the AJ30G411R55MA ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Faggiolati products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
