BRAND | Steimel |
Product | ASF4-112RD161410R |
Description | A-SF4/112RD-VLFM, pump unit, 2-16 bar |
Internal code | 4307729 |
Custom code | 84136039 |
Technical specification | 7.5 kW, 1500, 400/690V, 50Hz, IP55, F, B5, IE3, special build 1) 10 weeks Gear pump unit: SF 4/112 RD - VLFM Item no.: ASF4-112RD161410R Dimension sheet: DPA054D-161410R Spare parts list: DET054112RD—165R Suction & pressure connection: SAE 2 Chassis parts: EN-GJL-250 (GG-25) Waves: 16 Mn Cr S 5, egh. gears, noise opti.: EN-GJS-400-15 (GGG-40), ionitrated, helical Storage: multilayer MD Shaft seal: radial shaft seal Elastomers: FKM Conveying medium: lubricating oil Viscosity: 50-5000 cSt Temperature: 10-60°C flow rate: approx. 140/ 168 l/min. pressure: 5 bar Rotational speed: 1450 /1750 rpm pressure relief valve Opening pressure: 8 bar Setting range: 2-16 bar direction of rotation: right Trial run: yes, with HLPD 46 coupling: BKUA065-2438-301 Pump carrier with foot: BLF054300168LA21 three-phase motor: LDM132-04-074 (birkenbeul) Engine data: power 1/2:7.5/8.6 kW speed 1/2:1500/1800 rpm Voltage/frequency 1:400/ 690 volts at 50 Hz Voltage/frequency 2:460 volts at 60 Hz Efficiency class: IE3 with additional sign (without IE2) for Voltage/frequency: 380-420/660-720 V at 50/60 Hz 440-480 volts at 60 Hz Protection class: IP 55 Insulation class: F Design: B 5 Paint: primer HDO058 green Nameplate: ETY924-D-E—PE02 * building site: Engine terminal box: rotated 90° to the left at view of the motor shaft. pump: rotated 90°, suction connection down direction pump foot Engine nameplate: readable from above |
Discover the superior quality and performance of the Steimel ASF4-112RD161410R with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The ASF4-112RD161410R is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of ASF4-112RD161410R :
At RADWARD LTD , we offer the ASF4-112RD161410R at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the ASF4-112RD161410R ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Steimel products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
