BRAND | Alerton |
Product | AXM-10-4-8 |
Description | Expansion Module |
Internal code | 4941391 |
Technical specification | Expansion Module for the ACM Power - Unit requires 24 VAC, 50- 60 Hz, 20 VA minimum. Half-wave rectified. Output loads powered separately. 10 Inputs - Jumper-selectable, 12- bit universal inputs accept thermistor, dry contact, 0-5VDC, 4-20 mA, or 0-10 VDC signals. Inputs 1, 2, and 3 support pulsed inputs with 10 msec minimum pulse length. No external resistor is required for 4- 20 mA. 04 Binary Outputs - Binary outputs rated 24 VAC @ 0.5 A with Hand-Off-Auto (H-O-A) switches for manual override. H-OA status can be monitored in software. Power source isolated from AXM power. 08 Analog Outputs - Analog outputs are driven by precision D/A converter. DIP-switch configurable to provide 0-10 VDC or 0-20 mA. Each analog output has an H-O-A switch and potentiometer for manual override. H-O-A and potentiometer status can be monitored in software. Max Dimensions - 6.95” (176.5 mm) H X 4.95” (125.7 mm) W X 1.6“ (40.5 mm) D. Terminations - Removable header-type screw terminals simplify field wiring Environmental - 32-131°F (0-55° C). 0-95% RH, non-condensing Communications - Twisted-pair, multi-drop AXM communications bus to ACM base unit. |
Discover the superior quality and performance of the Alerton AXM-10-4-8 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The AXM-10-4-8 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of AXM-10-4-8 :
At RADWARD LTD , we offer the AXM-10-4-8 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the AXM-10-4-8 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Alerton products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
