| BRAND | CeTech |
| Product | CFIB - 2 - MA - 35H - ET - 0- 0 |
| Description | GLOBTOP CF series case mod. CFIB |
| Internal code | 5053093 |
| Technical specification | in aluminium alloy (copper ≤ 0.1%), with open/closed position indicator for rotary valves • ATEX certification (BVI 19 ATEX 0006): Ex II 2 GD — Ex db IIC T6/T5/T4 Ex tb IIIC T85/T100/T135°C (Tamb. from -50°C to +60/+80/+100°C) - Cable entry: n.3 3/4" npt-f holes - Terminal block: 3 terminals plus ground connection (option 12 terminals) - Degree of protection: IP66/67/67M (with shaft rotation test) - Surface treatment: chromation (compliant with MIL5541 Class 1A) + polyester coating (RAL7000) (maximum resistance to chemical and atmospheric agents) - Position indicator: three-dimensional dome in red-green color - Shaft: namur coupling — 316 stainless steel material Each case is equipped with 1 GO SWITCH (TOPWORX) with the following characteristics: - passive type 30 Model 35 Hermetic magnetic limit switch (without power supply and without reed contacts) - mechanical contact (snap action & dry contact): gold-plated SPDT in silver-cadmium; hermetic - contact capacity: 4A ac 120V ac, 2A c.a 240V ac and 3A dc 24V DC resistive load - sensitive distance: 3 mm. (with iron seal) - differential (hysteresis): 3 mm. (with iron seal) - response time: 8 milliseconds - working temperature: see T.amb. of enclosure certification - housing: cupronickel - nr.4 PVC insulated 105° connecting conductors |
Discover the superior quality and performance of the CeTech CFIB - 2 - MA - 35H - ET - 0- 0 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CFIB - 2 - MA - 35H - ET - 0- 0 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CFIB - 2 - MA - 35H - ET - 0- 0 :
At RADWARD LTD , we offer the CFIB - 2 - MA - 35H - ET - 0- 0 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the CFIB - 2 - MA - 35H - ET - 0- 0 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply CeTech products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
