BRAND | Tapflo |
Product | CTICC-1CGV-114 |
Description | pump |
Internal code | 4731528 |
Custom code | 84137081 |
Technical specification | Tapflo® industrial centrifugal pump Type CTICC-1CGV-114 Technical description: Max. flow rate 14 m³/h with water Max. delivery pressure 5 mWs Max. system pressure 10 bar Max. solid size 6 mm Suction height not self-priming Max. temperature 90°C Max. viscosity 200 mPas Case parts in contact with the product 316L stainless steel bead-blasted 316L stainless steel impeller Single-acting mechanical seal: ceramic/graphite/FKM (VITON) FKM O-ring housing (VITON) Suction connection 1 1/2 “external thread Pressure connection 1 1/2 “external thread Propulsion: Motor 3-phase 230/400 V, 50 Hz, 1.1 kW, IP 55, IE3 Speed 1450 rpm at 50 Hz Customs tariff number: 84137081 |
Discover the superior quality and performance of the Tapflo CTICC-1CGV-114 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CTICC-1CGV-114 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CTICC-1CGV-114 :
At RADWARD LTD , we offer the CTICC-1CGV-114 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the CTICC-1CGV-114 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Tapflo products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
