BRAND | Leybold |
Product | TRIVAC D16B-DOT |
Description | Two stage rotary vane pump |
Internal code | 4706102 |
Custom code | 84141025 |
Technical specification | Catalogue no. 11406 Features: Oil-sealed vacuum pump with integrated oil pump for Forced lubrication of bearings even at high suction pressures of 1013 mbar. The pump is free of non-ferrous metals and the inner part of the pump is metallically sealed i.e. no use of elastomer Seals that can be chemically attacked. The TRIVAC B The pump has a hydro-pneumatic suction port valve for vacuum protection and via a gas ballast device, with which it It is possible to pump condensable vapors. Engine certification: CSA, UR Pump certification: CE RoHS compliant Technical data: Suction rate according to DIN 28400:16.5 m³/h (50 Hz)/19.8 m³/h (60 Hz) Total pressure without gas ballast: < 6 · 10-1 mbar Final total pressure with gas ballast: < 9 · 10-1 mbar Sound level in accordance with DIN 45 635 with/with gas ballast: 54/56 dB (A) Dimensions (LxWxH): 510 x 186 x 250 mm Oil filling min/max: 0.5/1.0 l Including oil filling with DOT 4 Motor data: Rated power of the three-phase motor 750 W Rated speed: 1425 min-1 (50 Hz)/1730 min-1 (60 Hz) Efficiency class: IE3 Protection class: IP55 200-240 V; 50 Hz; 3.8 A/200-240 V; 60 Hz; 3.4 A 200 V; 50 Hz; 3.8 A (IE3= 82.5%) 208-240 V; 60 Hz; 3.4 A (IE3= 85.5%) 380-400 V; 50 Hz; 1.9 A/380-480 V; 60 Hz; 1.9 A 380-400 V; 50 Hz; 1.9 A (IE3= 82.5%) 416-480 V; 60 Hz; 1.7 A (IE3= 85.5%) Suitable for line voltages +/- 10% Suction flange: DN25KF can be used horizontally and vertically Outlet flange: DN25KF can be used horizontally and vertically Cooling: air equipment: Manual gas ballast setup (on/off) Inert gas connection for M16x1.5 gas ballast Inert gas connection for the M16x1.5 oil box oil drain and oil filler plug Box contents: user guide Spare parts list 2 x centering and clamping rings DOT 4 oil filling |
Discover the superior quality and performance of the Leybold TRIVAC D16B-DOT with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The TRIVAC D16B-DOT is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of TRIVAC D16B-DOT :
At RADWARD LTD , we offer the TRIVAC D16B-DOT at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the TRIVAC D16B-DOT ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Leybold products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
