| BRAND | Erhardt Leimer |
| Product | DC 9156 |
| Internal code | 3817323 |
| Weight | 1.55 |
| Custom code | 90328900 |
| Technical specification | Nr: 355850 DC 9156 digitaler Positionsregler im Gehäuse, Ausgangsspannung 22 V, Ausgangstrom 2 A, für digitale Sensoren, Betriebsspannung 24 V DC Maße: 150x150x80mm Farbe: Strukturlack schwarzgrau RAL 7021 matt |
Discover the superior quality and performance of the Erhardt Leimer DC 9156 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DC 9156 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DC 9156 :
At RADWARD LTD , we offer the DC 9156 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the DC 9156 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Erhardt Leimer products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Worm gear completely for tending side with hand wheel Series = 3 (motor / hand heel different sides) Version = left stretcher ________Fi_na_l_ c_ol_ou_r_ =_ R_A_L_ 1_0_1_5 _P_E_R_M_A_T_E_
screened cable
(PD 2145 load cell Flanged, per measurement M 057050 without ball bearings and retaining rings mm pin diameter 45 Design open on one side Nominal force 1.2 kN, protection IP 50 Technical specifications: Machine width: 2,030 mm Felt width: 1600 mm Felt draw: 1.23 N / mm Roll weight: 60 kg Bearing Type: (FYH) UK210 Shaft diameter: 45 mm Ambient temperature: 5 - 40 ° C Angle: -0.71 ° / -2.12 °)
(PDV 0200-60 shielded cable 4x A0,75 15 m 1 clutch, IP 50 Origin: European Union (DE) HS 85444290)
(F 31E edge sensor mechanically left, individually adjustable with 2 fine silver contacts for max. 60 V 0.2 A, control bandwidth From 0.5 to 30 mm and contact force of the sensing lever adjustable, protection IP 33, max. 80 degrees C including 2 m connecting cable)
ATL 0103 limit switch ATL with mounting without Limiting device to secure the Cheeks joints, with gold contacts
PD 2325 load cell made of stainless steel, Flanged, per measurement M 057332 without ball bearings and retaining rings mm stud diameter 25 Design open on one side Nominal load 0.15 kN, IP 65, including 5 meters of cable Origin: European Union (DE) ________H_S _9_03_1_8_09_8
FR5001 Magic eye left reflection plate
FR5001 Magic eye left reflection plate
CV 2201 Web tension measuring amplifier for DIN rail mounting, Operating voltage 24 V DC, Output 0-10 V or 0 / 4-20 mA
(CV 2201 Web tension measuring amplifier for DIN rail mounting, Operating voltage 24 V DC, Output 0-10 V or 0 / 4-20 mA Origin: European Union (DE) HS 85437090)
Control panel in desk housing
Controller module, digital with software
FR 5001 edge sensor digital, infrared, for flat homogeneous web edges, 057,785 per measurement, measurement range +/- 10 mm, with microprocessor, data protocol 1.0 LED indicator scale with keyboard, Plug for operating voltage 24 V and CAN-bus, IP 65 protection.
controller
2m Telescopic electric line
electric eye cable
00329557 FR 1501 KANTENSENSOR LINKS
FR 1501 left edge sensor
INFRARED EDGE SENSOR
SW_9500-9501 actuator digital +/- 75 M = 433 1000 N Origin: European Union (DE) HS84439199
00333787 FE 5002 mit Zylinderlinse
Farbliniensensor digital
Color line sensor digital,with cylindrical lens, per measurement 157272,Measuring range +/- 10 mm, membrane keyboard withLED display scale, pluggable,Operating voltage 24 V DC, IP 65Data Log 1.0Origin: European Union (DE)HS 85414090
(DC 5501 Digital Controller with housing with CAN controller card, Power stage PK 5511 and fans, and interfaces for Peripherals and software for KRS, Display Language: English / Chinese, Dimensions 283 x 232 mm x 111 Operating voltage 34 V AC 500 W Origin: European Union (DE) HS 90328900)
(Actuator per measurement 157987, DC gear motor, Incremental encoder output pinion, Rack lock Flanschsäule 362 mm long with clamping ring and mounting the sleeve for Actuator, IP 54 Force 1230 N Adjusting speed 120 mm / s Origin: European Union (DE) HS 84798997)
approach switch (including 5m cable)
