| BRAND | Micro-Epsilon (Eltrotec) |
| Product | DT3300 |
| Description | Controller |
| Internal code | 2592726 |
| Weight | 1 |
Discover the superior quality and performance of the Micro-Epsilon (Eltrotec) DT3300 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The DT3300 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of DT3300 :
At RADWARD LTD , we offer the DT3300 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the DT3300 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Micro-Epsilon (Eltrotec) products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Adaptation board adjusted for ES4 type sensor, cable length 3m and non-ferromagnetic target material; (mounted in the DT3300 type controller)
Adaptation board adjusted for EU8 type sensor, cable length 3m and non-ferromagnetic target material; (mounted in the DT3300 type controller)
Power supply, input 100-240 VAC, output +/-12 VDC and 5.2 VDC, with integral cable length 1.5 m and 7-pole female connector, for max. 4 multifunction controllers DT3300
Measuring range 0-1mm; mounting thread M8x1 with 3m (+/-15%) integral cable;
Shielded sensor Measuring range 1.0 mm mounting thread M8x1, sensor length 18 + 10 mm with 0.25 m integral coaxial cable (diameter 3 mm) and sealed triaxial female connector; max. operating temperature 150°C; housing material: stainless steel; compatible connecting cable: ECxx
Shielded sensor Measuring range 2 mm mounting thread M12x1, sensor length 25 mm with sealed triaxial female connector; pressure resistance (static): front 20bar and rearside splash water; max. operating temperature 150°C; housing material: stainless steel and plastics; compatible connecting cable: ECxx
Shielded sensor Measuring range 4 mm mounting thread M18x1, sensor length 25 mm with sealed triaxial female connector; pressure resistance (static): front 20bar and rearside splash water; max. operating temperature 150°C;housing material: stainless steel and plastics; compatible connecting cable: ECxx
Unshielded sensor Measuring range 8 mm mounting thread M24x1,5, sensor length 33,8 mm with sealed triaxial female connector; pressure resistance (static): front 20bar and rearside splash water; max. operating temperature 150°C; housing material: stainless steel and plastics; compatible connecting cable: ECxx
2901028 PC3/8 POWER AND OUTPUT CABLE
3 m long, with 8-pole female connector suitable to the signal conditioning controller, open ends for the connections
Supply and synchronisation cable, 0.3 m long with 7-pole male connector and 7-pole female connector suitable for multifunction controllers DT3300
cable
2903010 CE3 SENSOR CABLE EXTENSION 3M
(+/-0.45m)
EC3 Sensor cable, 3 m (+/-0.45 m) long with sealed triaxial straightline male and 5-pole female connector suitable to DT3300 type controller
Micrometer calibration fixture range 0-2,5mm, 1 micrometer/division; adjustable offset (zero), for sensors with range < 2 mm;
cable TM-TIM PIF process interface, 1m cable, integr. electronics
sensor
Signal conditioning electronics in compact aluminium housing,power supply 9 ... 36 VDC or +/- 15 VDC,output: 0 ... 10 V and 4 ... 20 mA;adjusted for ferromagnetic targetmaterial (reference mild steel St37),adjusted for sensor ... (Serial Number on theelectronics label) and ... m interconnecting cable
Multifunction Controller Single-channel electronics for eddy current displacement sensors, with integrated LC-grafic display, aluminium housing, Output: 0-10 Volt and current output 4 - 20 mA, feeding +/-12 VDC / 100 mA and 5.2 VDC / 220 mA
thermo TIM 160 thermal imaging camera 48 ° optics Infrared Camera with USB 2.0 port Temperature ranges: -20 ° C - 100 ° C, 0 ° C - 250 ° C, 150 ° C - 900 ° C (Switchable) Spectral range: 7.5 -13 microns Optical resolution: 160x120 pixels Thermal Resolution: 0,1 ° C Lens Focal length: f = 4.5 mm / 48 ° lens Emissivity: 0,1 - 1,0 adjustable Ambient temperature: 0 ° C - 50 ° C Storage temperature: -40 ° C - 70 ° C Protection: IP67 Signal output: USB2.0 Refresh rate: 120Hz
Compact-Verstärker
Compact-Verstärker
AMPLIFIER UNIT VAL0158388
infrared pyrometer
Miniature-pyrometer
