| BRAND | Georgin |
| Product | FP6NX |
| Internal code | 5023547 |
| Custom code | 90322000 |
| Technical specification | Pressure Switch F series Protection: IP66 Housing: mazak, epoxy painted, St. St. Screws Range: 0.1 to 2 bar max. pressure: 8 bar Sensing element: Bellows Material: 316L st. st. Process connection: 1/2""GM Switch: 1 tropicalized SPDT Adjusted deadband: <55 to 500 mbar Current rating: 10A/240VAC - 0.5A/110VDC Cable gland: polyamide M16 (Ø5-10) PED information: material complies mit PED 2014/68/EU Category IV Article reference: 0FP06BNSY0000 (Y instead of X: new generation with better material, technical identical) |
Discover the superior quality and performance of the Georgin FP6NX with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The FP6NX is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of FP6NX :
At RADWARD LTD , we offer the FP6NX at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the FP6NX ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Georgin products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Capillary temperature switch F series protection : IP66 housing : mazak, epoxy painted range: 20 to 95 ºC max. temperature : 105 ºC sensing element : 2m capillary- bulb Ø14x150mm material: 316Ti st. st. capillary protection : st. st. armor switch: 1 tropicalized SPDT adjust. deadband :(low/high of range)5-25ºC/1-8ºC currentrating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10) features: st. st. tag plate
Diff.pressure switch F series protection : IP66 housing : mazak, epoxy painted range : 50 to 1000 mbar min/max static pressure : 0 / 80 bar sensing element : diaphragm BunaN material : BunaN - 316L st. st. flange process connection : 1/4"NPTF switch : 1 tropicalized SPDT adjust. deadband : <90 to 200 mbar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10)
Pressure switch F series protection: IP66 hosuing: mazak, epoxy painted-st.st. screws range: -1 to 5 bar max. pressure : 13 bar sensing element : bellows materila: bronze process connection : 1/2"GM switch: 1 tropicalized SPDT fixed deadband : <165 mbar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10) features: st. st. tag plate Origin of material: FRANCE / E.U. European Customs Tariff Pressure Switch : 9032 2000
Ref. FP6PX 1 296,00 296,00 Pressure switch F series protection : IP66 housing : mazak, epoxy painted-st.st. screws range : 0.5 to 10 bar max. pressure : 15 bar sensing element : bellows material : 316L st. st. process connection : 1/2"GM switch : 1 tropicalized SPDT adjust. deadband : <0,24 to 2 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10)
Pressure switch F series protection : IP66 housing : mazak, epoxy painted range : 5 to 50 bar max. pressure : 80 bar sensing element : bellows material : 316L st. st. process connection : 1/2"NPTM switch : 1 tropicalized SPDT adjust. deadband : <1,4 to 10 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10)
Pressure switch F series protection : IP66 housing : mazak, epoxy painted range : 25 to 400 bar max. pressure : 600 bar sensing element : Bourdon tube material : 316Ti st. st. process connection : 1/2"NPTM switch : 1 tropicalized SPDT adjust. deadband : <32 to 200 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10)
(Pressure switch F series protection: IP66 housing: mazak, epoxy painted range: 2.5 to 25 bar max. pressure : 30 bar sensing element : bellows material: 316L st. st. process connection : 1/2"NPTM switch: 2 separate tropicalized SPDT adj. from : <0,6 to 5 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10) )
Diff.pressure switch P series protection : IP66 housing : mazak, epoxy painted range : 2 to 40 mbar max. static pressure : 3 bar sensing element : diaphragm BunaN material : BunaN - mazak flange process connection : 1/4"NPTF switch : 1 SPDT, dry contact adjust. deadband : <11 to 30 mbar current rating : 5A/240VAC - 0.5A/110VDC cable gland : polyamid M20 (Ø7.5-13)
Intrinsically Safe Control
Insulator 230V AC, input/output 4-20mA
Zener Barriere
Zener diode
range: 115-210 °C sensing element: 2 m capillary- bulb 9 mm diameter, 120 mm length, copper
Capillary temperature switch F series protection : IP66 / ATEX flame proof housing : Ex-proof in epoxy painted-st.st. screws range : -20 to +45 ºC max. temperature : 55 ºC sensing element : 4m capillary-bulb Ø14x150mmmaterial : 316Ti st. st. capillary protection : st. st. armor switch : 1 tropicalized SPDT adjust. deadband :(low/high of range)4-20ºC/1-7ºC current rating : 10A/240VAC - 0.5A/110VDC cable gland : as option (elect. connect. 3/4"NPTF) features: Ex d st. st. tag plate
Capillary temperature switch F series protection : IP66 / ATEX flame proof housing : Ex-proof in epoxy painted-st.st. screws range : 20 to 95 ºC max. temperature : 105 ºC sensing element : 4m capillary-bulb Ø14x150mm material : 316Ti st. st. capillary protection : st. st. armor switch : 1 tropicalized SPDT adjust. deadband :(low/high of range)5-25ºC/1-8ºC current rating : 10A/240VAC - 0.5A/110VDC cable gland : as option (elect. connect. 3/4"NPTF) features: Ex d st. st. tag plate
Pressure switch F series protection : IP66 / ATEX intrinsic safety housing : mazak, epoxy painted range : 5 to 50 bar max. pressure : 80 bar sensing element : bellows material : 316L st. st.
Pressure switch F series
Pressure switch
Pressure switch F series
(Gauge pressure transmitter... GR/GA series housting: stainless steel / protection: IP65 range : 0...50 bar maxi pressure : 150 bar sensor: ceramic cell on viton gasket process connection : 1/2" BSPM - st.st. 316 L electrical connector : DIN43650 power supply : 10...30Vdc output signal : 4...20 mA max. global error : 0.5% FS --------ATEX information------------ EC type examination certificate LCIE 01 ATEX 6137X Ex ia IIC T6 or T5 Ga (-30 Ta 55 or 70Celsius) Ex ia IIIC T80Celsius or T95Celsius Da (-30 Ta 55 Celsius or 70 Celsius Groupe II - category 1GD - Zones 0-1-2 or 20-21-2: Ex ia I - group I (MInes) -CAtegory Mi Production Notification LCIE 02 ATEX Q 8023 See leaflet for a safe use)
Drucktransmitter
Drucktransmitter
Drucktransmitter
SWITCH PRESSURE
(Pressure switch)
pressure Switch
(Pressure switch P series protection : IP66 housing : mazak, epoxy painted-st.st. screws range : 10 to 90 bar max. pressure : 250 bar sensing element : bellows material : 316L st. st. process connection : 1/2"NPTM switch : 2 simultaneous SPDT, dry contact adjust. deadband current rating : 5A/240VAC - 0.5A/110VDC cable gland : polyamid M20 (Ø7.5-13) features: st. st. tag plate)
material : PBT Goods of French / E.U. origin European Customs Tariff Pressure Switch : 9032 2000
