BRAND | LAIPPLE KEB |
Product | G33A DM80GC4 B03MB TS |
Description | helical gear motor |
Internal code | 4066787 |
Technical specification | Output speed: 26 1/min Torque: 280Nm Gearbox Coefficient: 1.70 Gearbox: Translation: 66.12 footprint Output shaft with feather key Ø30x60 Bleed valve Lubricant: 1.6 l CLP VG220 mineral oil Motor: three-phase motor IE2 Rated power: 0.75kW S1 Engine speed: 1690 rpm Voltage/frequency: Y 460V 60Hz Rated current: 1.66A cosφ: 0.73 Insulation class: 155 Degree of protection: IP65 Brake B03, 10Nm, 460VAC, air vent, 0 Motor protection: temperature switch (normally closed) UL version (C+US), file E256406 Dust and water protection Motor connection: Terminal box 2xM25+1xM16, position 0A Color: normal, RAL7031 blue-gray Installation position: M2 |
Discover the superior quality and performance of the LAIPPLE KEB G33A DM80GC4 B03MB TS with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The G33A DM80GC4 B03MB TS is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of G33A DM80GC4 B03MB TS :
At RADWARD LTD , we offer the G33A DM80GC4 B03MB TS at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the G33A DM80GC4 B03MB TS ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply LAIPPLE KEB products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
