| BRAND | Hitrol |
| Product | HT-100RS |
| Description | Magnetic Float Type Level Transmitter |
| Internal code | 3700895 |
| Weight | 1 |
| Technical specification | Model : HT-100RS Type : Magnetic Float (Resolution : ±10mm) Installation : Top Ambient Temperature : -20 ~ +60 deg.C Fluid Temperature : Max. 80 deg.C Operating Pressure : Up to 10kg/cm2 Power Source : DC 24V Output Signal : DC 4...20mA (2-Wire) Enclosure : Weather Proof, IP65 Wetted Parts Material : 316LSS Housing Material : AL. Process Connection Size : ANSI 3" 150# RF Process Connection Material : 316LSS Measuring Length : L = 860mm, L1 = 100mm, L2 = 760mm Float Size / Material : 3" (ø73x105H) / 316LSS / Guide Pipe : ø21.7 Cable Entry : PF 3/4"(F) Medium : Water Reference Serial No. : 1207087001 |
Discover the superior quality and performance of the Hitrol HT-100RS with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The HT-100RS is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of HT-100RS :
At RADWARD LTD , we offer the HT-100RS at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the HT-100RS ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Hitrol products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
