Buy KF55-L/2-P5K M16-LH / M12-RH from HIMMEL in United Kingdom

BRAND	HIMMEL
Product	KF55-L/2-P5K M16-LH / M12-RH
Internal code	5015899
Technical specification	2260000188 Motor number: 870341 HIMMEL® flat motor KF55-L/2-P5K M16-LH/M12-RH Circular and face tolerances according to F = fine Only brake the spring-action brake at < 3600 rpm *Circular and face tolerances according to F = fine Dimension sheet: 1NJ004476 K model series/design series: K55 Type/type: KF55-L/2-P5K K-size sheet/dimension sheet: 1NJ004476 Color/colour: RAL 5015 sky blue 2K/sky blue 2K-PUR Design/mounting position: B3 K-mounting sides: one-sided foot machining/one-sided foot machining Protection class: IP54 K-rating plate/name plate: adhesive label 90x60 /adhesive label 90x60 Rating plate logo/name plate logo: SKY Customs tariff number/HS code: 85015220 Ambient temperature/ Ambient temperature /Ta [°C]: -20/+40 Output variant/Output variant: Shaft with spring fit/Shaft with parallel key W.diameter/shaft diameter [mm]: 30 W. length/shaft length [mm]: 68 (free shaft end) Wave thread/shaft thread: M16-L.H. + M12-R.H. Bearing AS/Bearing-AS (DE): Double row angular ball bearing Contact ball bearing Bearing BS/Bearing-BS (NDE): simple bearing K-elect.connection type/elec. connection mode: terminal box/ terminal box KK material/Terminal box material: aluminum/aluminum KK location/Terminal box position: 2BK KK screw connection/gland: (2x) -M20x1.5 + (4x) -M12x1.5 Label/Approval\|Identification/Certification: CE Number of phases: 3~ Number of poles/poles: 2 Rated power/nominal power [kW]: 2.4 Nominal motor speed/Nominal motor speed [1/min; rpm]: 5530 Rated frequency/ Nominal frequency [Hz]: 100 Rated voltage/nominal voltage [V]: 400 Rated current/Nominal current In [A]: 5.10 CosPhi/CosPHI: 0.84 Circuit/ Wiring: S101 (Y) Operating mode/Duty type: S1 Type of supply/power supply: FU-operation/ inverter duty Drive protection/motor protection (IEC60034-25): to be guaranteed by system managers/to be Guaranteed by System Manager Winding protection/Motor protector: PTC 160°C Insulation class: F Motor circuit diagram/Motor connection diagram: A0101000 Circuit diagram built-in 1/Con. diagram compon. 1: A01TP000 Brake type: P5K Brake control voltage [V]: 360-440 Wiring/Connection: separate/separate Brake 1 circuit diagram/Brake connection diagram 1: A01BA000

Discover the superior quality and performance of the HIMMEL KF55-L/2-P5K M16-LH / M12-RH with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The KF55-L/2-P5K M16-LH / M12-RH is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of KF55-L/2-P5K M16-LH / M12-RH :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At RADWARD LTD , we offer the KF55-L/2-P5K M16-LH / M12-RH at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose RADWARD LTD ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the KF55-L/2-P5K M16-LH / M12-RH ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply HIMMEL products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
