| BRAND | Badger Meter |
| Product | LIQUID FLOW METER RCDL M70, WITH PULSE GENERATOR PFT-1E. |
| Description | Body: Bronze Measuring chamber: Vectra O-rings: Viton Measuring range: 18 - 265 l / min Accuracy: + / - 1.5% of the value p-max: 16 bar t-max: 120 ° C Connection: R 1 1/4 "male Length: 273 mm Mounting position: horizontal, vertical Pulse Output: Transistor NPN open Scale Factor: 0.00001 to 0.9999 Supply: 12-24 VDC |
| Internal code | 331044 |
| Weight | 1 |
Discover the superior quality and performance of the Badger Meter LIQUID FLOW METER RCDL M70, WITH PULSE GENERATOR PFT-1E. with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The LIQUID FLOW METER RCDL M70, WITH PULSE GENERATOR PFT-1E. is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of LIQUID FLOW METER RCDL M70, WITH PULSE GENERATOR PFT-1E. :
At RADWARD LTD , we offer the LIQUID FLOW METER RCDL M70, WITH PULSE GENERATOR PFT-1E. at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the LIQUID FLOW METER RCDL M70, WITH PULSE GENERATOR PFT-1E. ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Badger Meter products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
(Type: 250BR - 1,25" bronze tee type meter.)
M2000 DN 40 dairy fitting Material and technical data: Measuring tube: Stainless steel 1.4571 Liner: PTFE Housing: stainless steel 1.4301 Protection class: IP 67 Connection: screw connection DIN 11851 / stainless steel 1.4571 (Dairy) Electrodes: Hasteloy C Min conductivity. 5 S / cm (20 S / cm demi. Water) Measuring range: 0.03 to 12 m / s Accuracy: ± 0,2% of reading ± 1 mm / s Nominal pressure: 16 bar Overall length: 225 mm Run transmitter: M2000 Mounting: built Housing: cast aluminum painted in IP 67 Display: LCD, 4 lines / 20 digits, backlit Outputs: Analog output 0/4 - 20 mA : Scalable pulse max. 10 kHz : Min / Max + Status + direction indicator Configuration: 3 buttons Interfaces: RS 232, Modbus RTU Leerrohrdet. : On off Supply: 85 - 265 VAC
WATER FLOW
Magnetic-inductive flowmeter
9008527MID M 1000 mit Flansch DN 50 ST 37
MID M 1000 with flange DN 50 ST 37 Hard rubber Hastelloy C 230VAC Magnetic-inductive flowmeters Type "Magneto Flow M1000 AM". Transducer: Type II Process connection: flange EN 1092-1 / St. 37 DN / PN: 50/16 * Measuring range: 3.6 to 1200 l / min Installation length: 225 mm Lining: hard rubber Max. Temp. 80 ° C Electrodes: Measurement and idle electrodes Elec Material: Hastelloy C Housing: St. 37 painted gray Transmitters: Type M1000 AM Assembly: Assembled version Software language: English / German * Units: Metric Current output: 0 / 4-20 mA * Endwertskala: standard (2.5 m / s) Pulse output: 24 V DC active / passive * Pulse rate: 1 PPL LCD display: 4 lines Read flow: 8 digits (unidirectional / bidirectional) 2 totalizers: 14 digits Protection: IP 67 Power supply: 92 to 275 VAC Min.Leitfähigkeit: 5 microS / cm Accuracy: +/- 0.3% of the measured value
ELECTRODES, WITH METER MOUNTED PRIMO AMPLIFIER, 316 SS GROUNDING RINGS
SN: 0506-067 0-75 meters for DN 50 Electromagnetic Flowmeter 3 x (2 x 0.25 mm²) + Ground of 160 Ω / km
MID M 1000 flange ISO DN 100 PN 16 Hard rubber Hastelloy C 230VAC
MID M 1000 with ISO flange DN 150 Hard rubber Hastelloy C 230VAC
for petrol, oil, digital and electronic counters, rotary platforms ½, flow. 0-28 I / min
Product preset Max 120°F/50°C Min 20°F/-5°C 868 mhz
Einbauzähler mit Impulsgeber für Schmieröl
ELECTROMAGNETIC FLOW METER
MAGNETOFLOW TYP II DN 65 / PN 16
Magnetic flowmeter with transmitter M1500 for full pipes.
MID 2-100/16-F/ST-WG-ML/HC-ST M15A SK1
Type II DN 100 / PN 16 with amplifier M1500 for full pipes
MID 2-25/16-F/ST-HG-MEL/HC-ST M15D obsolete, replacement MID 2-25/16-F/St-HG-MEL/HC-St M10DM
(P/N 9005257) M1500 (24 VDC)
MID M 1000 MIT FLANSCH DN 32 HARTGUMMI HASTELLOY C 24VDC
Magnetic flowmeter Magneto Flow Type II DN 32 / PN 16 with transmitter for M2000 full pipes.
schetchik jidkosti
MN SERİES,70-733 LPM 1200 KPA 3”/80MM BSP
BADGER METER RCDL DISC METERS POSITIVE DISPLACEMENT – NUTATING DISC
Register with pulse output, Electronic counter LCR type with an LCD display and, pulse output above for OG-Baureihe.Anzeige 1: resettable totalizer or flow indication programmable, Format xxxx.x. Display 2: Non-resettable totalizer, 14 digits. Memory display: EEPROM, data retention in battery replacement Units: liters, gallons, pints, quarts Temperature: 0-70 ° C Pulse acquisition: Reed, max.50Hz Input pulse: from 1.00 to 17000.00 (numerator) Correction factor: 0.5000 to 2.0000 Power supply: 3 VDC Lithium CR 1/2 AA Protection: IP 64 For counter Size: M25-M35-M40-M70-M120-M170 Pulse output: NPN, MOSFET 40V / 2A Pulse factor: 0.01-99.99 Pulse length: 10ms (2ms, 20ms, 40ms) Ext.Stromversorg. : 8-24VDC Pulse output PPL: 0,01-0,1-1-10-100 Dosing control: 0.01 to 999.99 Preliminary circuit: from 0.00 to 99.99 Switching output: NPN, MOSFET 40V / 2A
RCDL LCR REGISTER MIT IMPULSAUSGANG U. STROMAUSGANG 4-20MA
Electronic counter LCR type with an LCD display, Display 1: resettable totalizer or Flow display programmable, Format xxx.xx. Display 2: Non-resettable totalizer 14 digits. Memory display: EEPROM, data retention in battery replacement Units: liters, gallons, pints, quarts Temperature: 0-70 ° C Pulse acquisition: Reed, max.50Hz Input pulse: from 1.00 to 17000.00 (numerator) Correction factor: 0.5000 to 2.0000 Power supply: 3 VDC Lithium CR 1/2 AA
RCDL LCR REGISTER OHNE IMPULSAUSGANG
Electronic counter LCR type with an LCD display, for the OG series Display 1: resettable totalizer or Flow display programmable, format xxxx.x Display 2: Non-resettable totalizer 14 digits Memory display: EEPROM, data retention in battery replacement Units: liters, gallons, pints, quarts Temperature: 0-70 ° C Pulse acquisition: Reed, max.50Hz Input pulse: from 1.00 to 17000.00 (numerator) Correction factor: 0.5000 to 2.0000 Power supply: 3 VDC Lithium CR 1/2 AA Protection: IP 64
3/4 "or 1" PPO Viton without pulse, fluid meter RCDL M25 without construction. Material and technical data: Housing: Nylon Measuring chamber: Noryl (PPO) O-rings: Viton Measuring range: 1-100 l / min Accuracy: +/- 1.5% of the value p-max: 10 bar t-max: 50 ° C Connection: R 3/4 "or R 1" Installation length: 190 mm Installation position: horizontal, standing
