| BRAND | Turck |
| Product | LT3NUQ-71361 |
| Description | LASER SENSOR |
| Internal code | 762635 |
| Weight | 1 |
| Technical specification | LT3NUQ-71361 LOW THRESHOLD Part Number: 71361 Max Measurement Range: >1 m - <=20 m Power: DC Sensing Beam: Visible Red Laser PC Configurable: No Sensing Mode (General): Proximity Sensing Mode (Detailed): Time of Flight Housing Style: Rectangular Primary Housing Material: ABS/Polycarbonate Laser Classification: Class 2 Input/Output: Analog Indicator: LED(s) Analog Output Configuration: 0-10 V dc Connection: Integral QD Analog Resolution/Discrete Repeatability: 1 to 1.25 at slow response speed Quick Disconnect Type: M12 Max Sensing Distance (mm): 5000 Minimum Sensing Distance (mm): 300 Power Supply: 12-24 V dc Delay at Power-up (ms): 1000 Sensing Beam Wavelength (nm): 658 Adjustments Push Button; Remote Teach Temperature Effect (mm/°C): 2 mm/° C Number of Pins: 8 Output Saturation Voltage NPN Outputs: < 0.2 V at 10 mA; < 0.6 V at 100 mA Output Saturation Voltage PNP Outputs: < 1.2 V at 10 mA; < 1.6 V at 100 mA Analog Voltage Output Rating: 2.5 kΩ min. load impedance Max Discrete (Switched) Output (mA): 100 Discrete (Switched) Outputs: 1 NPN Output Protection Protected against short circuit conditions IP Rating IP67 NEMA Rating NEMA 6 Max Operating Temperature (°C) 50 Max Op. Relative Humidity Non-Condensing (%) 90 at 50°C Window Material Acrylic Warm-up Time (minutes) 30 Minimum Response Time (ms) 1 Spot Size (@ Reference Distance) 6 mm @ 3 m Analog Linearity (mm) +/- 30 mm from 0.3 to 1.5 m; +/- 20 mm from 1.5 to 5 m Minimum Window Size (mm) 20 Color Sensitivity (Typical) 90% white to 18% gray: <10 mm; 90% white to 6% black: < 20 mm Remote Teach and Laser Control Input Impedence: 18 kΩ min. (65 kΩ min at 5 V dc) Discrete Output Hysteresis (mm): 3 Laser Control: Yes Max Off-state Leakage Current (µA): 5 Power/Current Consumption (exclusive of load): 108 mA max @ 24 V dc Supply Protection Circuitry: Protected against reverse polarity and transient overvoltages Typical Laser Lifetime (Hours): 75000 Feature: Remote Teach: Yes Feature: Washdown Rated: Yes Feature: Timing (Hold/Delay): No Feature: Chemical Resistant: No Feature: Quick Disconnect: Yes Common Ethernet Protocol: No IO Link - No RS-232 - No RS-422 - No RS-485 - No SSI - No Wireless - No 1-wire Serial Interface: No Profibus: No |
Discover the superior quality and performance of the Turck LT3NUQ-71361 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The LT3NUQ-71361 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of LT3NUQ-71361 :
At RADWARD LTD , we offer the LT3NUQ-71361 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the LT3NUQ-71361 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Turck products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
