BRAND | Rsf Elektronik |
Product | MSA670 ( 1298012-H7) |
Internal code | 4761778 |
Custom code | 90319000 |
Technical specification | Measuring length: 1020 mm Accuracy class: ± 10.0 μm Division period: 20,000 μm Output signal: square signals, TTL level with 1-way interpolation not clocked Reference mark position: in the middle of the measurement length Sealing type: NBR sealing lip Voltage supply: 5 V (+-10%) Minimum edge spacing: 3.300 μs Fault signal: OT Reference pulse width: 90° Limit switch: without Connection direction: cable outlet on the right Cable length: 3.00 m Electrical connection: Sub-D plug, metallized plastic housing, 2-row, with locking screws, 15-pin pin Port configuration: D1143258 Cable type: PUR Ø 4.3 mm |
Discover the superior quality and performance of the Rsf Elektronik MSA670 ( 1298012-H7) with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The MSA670 ( 1298012-H7) is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of MSA670 ( 1298012-H7) :
At RADWARD LTD , we offer the MSA670 ( 1298012-H7) at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the MSA670 ( 1298012-H7) ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Rsf Elektronik products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
