BRAND | Sensus |
Product | MSTMM20A / MeiStream Q3 250 m³/h |
Description | Large water meter |
Internal code | 4955204 |
Technical specification | Construction length 300 mm Woltmann water meter MeiStream Plus DN150 300mm Q3_250 R315 PN16 Horizontal installation, cold water up to 50 °C Catalog number: MSTMM201 Nominal diameter (DN) DN 150 Product type Counter Meistream Plus product version Pressure level PN16 Construction length 300 mm Drilling pattern EN 1092 PN16 Cobalt blue (cold) /tin RAL 5013 coating Metrology 2014/32/EU (MID) Module H1 Nominal flow rate Q3 = 250 m³/h Class/Ratio (measurement ratio) R315 ROAD Horizontal installation position (H) Temperature label T 50 TVO KTW+W270 (default) Mechanical counter m³ unit Housing/ME auxiliary flow rectifier (SGR) Sampled pointer Unspecified Woltmann dry runner with encapsulated counter. Rotatable counter. Measuring vane parallel to the pipe axis. * universal installation position (“plus” version only horizontal) * standard HRI AMR interface for remote reading or M-Bus * optional: e-register with integrated radio readout . Special design features: * “floating impeller” for maximum measurement accuracy * Measuring inserts (cold water) compatible with WP-Dynamic design * available in all standard lengths (WP and WS) * very high load capacity * minimized wear * unique measurement range * flood-proof in accordance with protection class IP 68 Technical data in accordance with list sheet LB 1010, LB 1020, LB 1060, LB 1080 |
Discover the superior quality and performance of the Sensus MSTMM20A / MeiStream Q3 250 m³/h with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The MSTMM20A / MeiStream Q3 250 m³/h is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of MSTMM20A / MeiStream Q3 250 m³/h :
At RADWARD LTD , we offer the MSTMM20A / MeiStream Q3 250 m³/h at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the MSTMM20A / MeiStream Q3 250 m³/h ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Sensus products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
