BRAND | POMPE CUCCHI SRL |
Product | MX 150/C |
Description | Bareshaft pump |
Internal code | 4441993 |
Technical specification | Pump type M0X150W0ADN0004 Body and cover in AISI 316 Mechanical seal in ceramic/graphite/FPM Shaft in AISI 316L and gears in AISI 316L with heat treatment Bushes in sintered material DU Pump without heating chamber and with heat treatment Bare Shaft Pump Rotation direction counterclockwise (view motor side) Liquid OIL Viscosity 50 mPas @ PT Liquid temperature 30°C Ambient temperature +5°C/+35°C Flow 9.000 Lt/h Suction pressure 0 BAR Discharge pressure 15 BAR Differetial pressure 15 BAR Connections orientation horizontal Connections 2" WELD IN Speed rotation 1450 rpm @ 50Hz Pump painting RAL gray 7010 ATEX rules confornity Cat. 2G - zone 1 - class temperature T4 |
Discover the superior quality and performance of the POMPE CUCCHI SRL MX 150/C with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The MX 150/C is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of MX 150/C :
At RADWARD LTD , we offer the MX 150/C at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the MX 150/C ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply POMPE CUCCHI SRL products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Position 10 Gear pump
DRIVER SHAFT
DRIVEN SHAFT
DRIVER GEAR
DRIVER GEAR IN PLASTIC
BUSH
DOWEL PIN
PTFE O-RING
FLAT GASKET
LANTERN CENTERING RING
MAGNETIC COVER
INNER MAGNET
EXTERNAL MAGNET
KEY
MAGNET WASHER
SCREW
SCREW
PTFE O-RING
COUPLING ATEX
SCREW
DRIVER SHAFT
O-RING
