BRAND | Ruwac |
Product | 74295 -A NA 35-D1 TYPE III – 2.20 KW Zone 22 |
Internal code | 5030835 |
Technical specification | Ruwac - NA35 WSP Type III Zone 22, hub separator for separating dry, humid, hot, gliding and explosive media in a flash. Model NA35 WSP chassis version Power 2.20kW Voltage+frequency 3x400V, 50Hz, IE3 Zone 22 II3D marking Air flow max. 300 cbm/h Low pressure-max. 206 mbar exhaust air connection exhaust diffuser, <70 dB (A) According to DIN EN ISO 3744 fill capacity 35 liters Raw gas side boiler connection 50 mm @ aluminum Stainless steel swirl screen, 10 x 10 mm hole Viewing window 150 x 60 mm, mounted in the first intermediate ring after the turbulence screen Degassing valve mounted left and right below the prefilter Stainless steel demister mat filter diameter 260 mm x 50 mm Residual dust filter cartridge 2 x 1.7 m? dissipative type AL (aluminum) Dust class M Optical fill level control via drain hose Drain hose 25 mm diameter and a DN200 flap for rough dirt For easy opening with a foot lever tension lock off the prefilter, galvanised steel wheelset 2 x 125 mm @, dissipative, with parking brake Negative pressure monitoring 2 x 300 mm @, pneumatic tires, mounted on the push handle side Pressure gauge with scale -250 mbar and red brand pointer adjustable |
Discover the superior quality and performance of the Ruwac 74295 -A NA 35-D1 TYPE III – 2.20 KW Zone 22 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 74295 -A NA 35-D1 TYPE III – 2.20 KW Zone 22 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 74295 -A NA 35-D1 TYPE III – 2.20 KW Zone 22 :
At RADWARD LTD , we offer the 74295 -A NA 35-D1 TYPE III – 2.20 KW Zone 22 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the 74295 -A NA 35-D1 TYPE III – 2.20 KW Zone 22 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Ruwac products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
