| BRAND | Ifm |
| Product | PC3552 |
| Description | Pressure transmitter |
| Internal code | 1120018 |
| Weight | 1 |
| Custom code | 90262020 |
| Technical specification | Elektronischer Drucksensor; Steckverbindung Product characteristics Number of inputs and outputs Number of analogue outputs: 1 Measuring range [bar] 0...40 Process connection threaded connection G 1/4 external thread Application Application for industrial applications Media liquids and gases Medium temperature [°C] -25...90 Min. bursting pressure [bar] 1000 Pressure rating [bar] 200 Type of pressure relative pressure Electrical data Operating voltage [V] 8.5...36 DC Min. insulation resistance [MΩ] 100; (500 V DC) Protection class III Reverse polarity protection yes Inputs / outputs Number of inputs and outputs Number of analogue outputs: 1 Outputs Total number of outputs 1 Output signal analogue signal Number of analogue outputs 1 Analogue current output [mA] 4...20 Max. load [Ω] 775; (Ub = 24 V; (Ub - 8,5 V) / 20 mA) Measuring/setting range Measuring range [bar] 0...40 Accuracy / deviations Repeatability [% of the span] < ± 0,15; (with temperature fluctuations < 10 K) Characteristics deviation [% of the span] < ± 2,0; (incl. drift when overtightened, zero point and span error) Linearity deviation [% of the span] < ± 0,25 (BFSL) / < ± 0,5 (LS) Hysteresis deviation [% of the span] < ± 0,2 Long-term stability [% of the span] < ± 0,05; (per 6 months) Temperature coefficient zero point [% of the span / 10 K] < ± 0,15; (-25...90 °C) Temperature coefficient span [% of the span / 10 K] < ± 0,2; (-25...90 °C) |
Discover the superior quality and performance of the Ifm PC3552 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The PC3552 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of PC3552 :
At RADWARD LTD , we offer the PC3552 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the PC3552 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Ifm products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
