BRAND | Hioki |
Product | PD3259-50 |
Description | DIGITAL PHASE DETECTOR |
Internal code | 4713645 |
Technical specification | Measurement parameters Three-phase AC voltage (line-to-line voltage and voltage to ground), Frequency • Voltage measurement accuracy: ±2.0% rdg. ±8 dgt., • Frequency measurement accuracy: ±0.5% rdg. ±1 dgt., • Response time: 3 s or less, Display update rate: 500 ms Measurement targets Covered cables, Metal portions *Use on shielded cables not supported Three-phase 90.0 to 520.0 V AC (45 to 66 Hz) Diameter of measurable conductors Finished outer diameter: 6 to 30 mm (0.24 to 1.18 in) Maximum rated voltage to earth 600 V AC (CAT IV) Environmental protection Main unit (excluding voltage sensors): IP54 (EN60529) dustproof and waterproof Other functions Hold function, Backlight, Buzzer, Auto power-off, Low battery warning, Drop proof (on concrete, 1 m/ 1 time) Power supply AA alkaline batteries (LR6) ×4, Maximum rated power: 3 VA, Continuous operating time: 5 hours (Backlight off, standby state, Without Z3210) Dimensions and mass 84 mm (3.31 in)W × 146 mm (5.75 in)H × 46 mm (1.81 in)D, 590 g (20.8 oz, including batteries), cord length: 0.5 m (1.64 ft) Included accessories AA alkaline batteries (LR6) ×4, Instruction manual ×1, Carrying case C0203 ×1, Color clip (White ×2, red ×2, blue ×2, yellow ×2), Spiral tubes (black ×1) |
Discover the superior quality and performance of the Hioki PD3259-50 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The PD3259-50 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of PD3259-50 :
At RADWARD LTD , we offer the PD3259-50 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the PD3259-50 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Hioki products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
