| BRAND | Burkert |
| Product | PN: 00306547 Type: 6281 |
| Description | 2/2-way solenoid valve |
| Internal code | 4045164 |
| Custom code | 84818079 |
| Technical specification | 6281-EV-A13.0FFMSNM84-5-024/DC-08* JG30+NA38+PE95+PU09 Mode of operation A 2/2-way; closed in rest position Nominal size 13.0 13 mm FF FKM sealing material Material: MS brass. Line connection NM84 NPT 1/2 female Spool size 5 32 mm Voltage 024 24 volts Frequency DC direct current Power consumption 08 8 watts Special feature JG30 connector type 2509 NA38 coil material insulation class H PE95 UL (UL listed) approval PU09 coil UL Recognized for USA and Canada cURus Min. pressure: 0.20 bar. pressure max. 16 bar KV 3.80 m3/h QNN 4,100 l/min Medium speed min 0 °C Medium speed max 120 °C Ambient temp. min 0 °C Ambient temp. max 55 °C |
Discover the superior quality and performance of the Burkert PN: 00306547 Type: 6281 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The PN: 00306547 Type: 6281 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of PN: 00306547 Type: 6281 :
At RADWARD LTD , we offer the PN: 00306547 Type: 6281 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the PN: 00306547 Type: 6281 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Burkert products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy PN: 00306547 Type: 6281 by Burkert in United Kingdom?
You can purchase PN: 00306547 Type: 6281 by Burkert from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the PN: 00306547 Type: 6281?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Burkert in United Kingdom?
While we are not the official distributor or seller of Burkert in United Kingdom, we source our products from reliable channels and offer you original Burkert equipment at competitive prices.
How can I access PN: 00306547 Type: 6281 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for PN: 00306547 Type: 6281 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for PN: 00306547 Type: 6281?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
PVDF BODY
2/2-WEGE-FLIPPERVENTIL 10MM GP
Type 6124 6124 Function A 2/2-way; Normally closed Nominal size 00,6 0,6 mm Seal material FKM FF Material PK PEEK Line connection flange FB08: 10 X 18mm 6603/6604 Coil size 0 Type Based specified Voltage 024 volts 24 Frequency BA battery power Power consumption 1.5 watt AC Special JF80 mm rectangular connector 5:08, 2-pole Pressure range -1 - 3 bar Pressure max / gas 3 bar Weight: kg / St 0.015
2/2-WEGE-FLIPPERVENTIL 10MM GP 00144120
Type 6124 6124 Function A 2/2-way; Normally closed Nominal size 00,6 0,6 mm Seal material FKM FF Material PK PEEK Line connection flange FB08: 10 X 18mm 6603/6604 Coil size 0 Type Based specified Voltage 012 volts 12 Frequency BA battery power Power consumption 1.5 watt AC Special JF80 mm rectangular connector 5:08, 2-pole Pressure range -1 - 3 bar Pressure max / gas 3 bar Weight: kg / St 0.015
2/2-WEGE-MAGNETVENTIL, DIREKTWIRKEND
(Type 0255)
2/2-way piston control angle seat valve
gasket kit
35gradusa 11bar CM25
½ PMed Pilot 5-10b diaphragm membrane 10b for valves 15 (DN 15) EPDM
00141576 W33LP
valve D13.5 Pmax 10bar Pilote 4.7 bar MiCR 191930J,THE FOLLOWING PARTS, THE SPRINGS AND MEMBRANE DN8 EPDM
2/2 way solenoid valve
positively controlled 2/2-way solenoid valve, Type 6213 6213 generation EV Function A 2/2-way; Normally closed nominal diameter 25.0 mm 25 Seal material FKM FF Material Stainless steel VA GM86 line connection socket G 1 Coil size L 65 mm Voltage 024 volts 24 Frequency DC DC Power 28 28 Watt Special NA38 coil for higher temperatures Pressure range 0 - 10 bar
PH METER
0-250 V AC / DC FA 1533
solenoid
LEVEL GAUGE
SOLENOID VALVE 3/2; 24VCC; 2W; G1/4
PVDF BODY
3/2-UND 5/2-WEGE-PNEUMATIKVENTIL 32MM
Type 6519 6519 Mode of action W Optional 5 / 2- or 3/2-way Nominal width of 6 mm 06,0 Line connection 1 GM82 G 1/4 sleeve Line connection 2 FS05 flange laterally Namurflansch Actuation B electro / pneumatic spring + mech. feather Coil size 5 32 mm Voltage 230 230 Volt Frequency 56 Hz 50-60 Power consumption 02 watts 2 Pressure range 2 - 8 bar Weight: kg / pc 0.513
3/2-WEGE-FLIPPERVENTIL 10MM GP
Type 6124 6124 Action of T 3/2-way; Universal Einset 3/2-way; Universal used Nominal size 00,6 0,6 mm Seal material FKM FF Material PK PEEK Line connection flange FB08: 10 X 18mm 6603/6604 Coil size 0 Type Based specified Voltage 024 volts 24 Frequency BA battery power Power consumption 1.5 watt AC JF80 rectangular connector, 5.08 mm, 2 poles Pressure range -1 - 3 bar Pressure max / gas 3 bar Weight: kg / St 0.015
