BRAND | Rembe |
Product | Q-Flap (DN 630 ) |
Internal code | 4965036 |
Technical specification | Q-Flap Q-Flap RX™ DN630 Product no.: 48900070 Explosion check valve for explosion-technical decoupling of explosions organic dust in pipes. Certification: ATEX 2014/34/EU Test standard: DIN EN 16447:2014 EU type examination certificate: GEX 19 ATEX 1004 X nominal diameter (DN): 630 mm Minimum allowance Operating temperature: 1 °C Max. allowable Operating temperature: 100 °C Max. Kst value: 250 bar x m/s Min. protected volume: ≥ 2.77 m³ Min. installation distance: 3,500 mm Maximum installation distance: 9,500 mm Maximum pred: 0.77 bar g Maximum pex: 1.03 bar g Flange standard: DIN 24154 series 2 Installation position: horizontal Operating conditions: pull flow Case: mild steel Sealing process side: EPDM FDA certified seal: yes Color: RAL 1906045 Installation length: 826 mm Weight: 140 kg Min. flow rate: 12 m/s Max. flow rate: 35 m/s Maximum dust load: 100 g/m³ Switch: without Locking mechanism: included Customs tariff number: 84813091 |
Discover the superior quality and performance of the Rembe Q-Flap (DN 630 ) with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The Q-Flap (DN 630 ) is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of Q-Flap (DN 630 ) :
At RADWARD LTD , we offer the Q-Flap (DN 630 ) at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the Q-Flap (DN 630 ) ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Rembe products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
signal membrane
Domed, tension-loaded, three-part rupture disc
