SF3/32RD-VLFM / ASF3-32RD- (031459 Steimel

Buy SF3/32RD-VLFM / ASF3-32RD- (031459 from Steimel in United Kingdom

BRAND	Steimel
Product	SF3/32RD-VLFM / ASF3-32RD- (031459
Internal code	4751519
Technical specification	Gear pump unit: SF 3/32 RD - VLFM Product no.: ASF3-32RD- (031459) Dimension sheet: DPA053 Spare part list: DET053 Suction and pressure connection: SAE 1 1/2 Case parts: EN-GJL-250 (GG-25) Sprocket shafts, noiseless: 16MnCrS5, helically toothed Storage: multi-layer MD Shaft seal: radial shaft seal Elastomers: FKM Delivery medium: Shell Madrela AS 32 Viscosity: 15-120 cSt Flow rate: 48/58 l/min. Pressure: 2.5 bar Speed: 1450/1750 1/min. pressure relief valve Setting range: 2-20 bar Opening pressure: 8 bar Direction of rotation: left Test run: yes, with HLPD 46 Coupling: BKUA040-1924-301 Pump support with foot: BLF053200118LA21 Three-phase motor: LDM090-04-174 (Birkenbeul) Power: 1.5 kW Speed: 1500/1800 rpm Voltage: 230/400 volts at 50Hz 460 volt star at 60Hz Frequency: 50/60 Hz Protection class: IP 55 Insulation class: F Efficiency: IE3 Special feature: CSA/UL version electr. according to NEMA Design: B 5 Aggregate paint: primed Identification plate: ETY924-D/E--PE02

Discover the superior quality and performance of the Steimel SF3/32RD-VLFM / ASF3-32RD- (031459 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The SF3/32RD-VLFM / ASF3-32RD- (031459 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of SF3/32RD-VLFM / ASF3-32RD- (031459 :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At RADWARD LTD , we offer the SF3/32RD-VLFM / ASF3-32RD- (031459 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose RADWARD LTD ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the SF3/32RD-VLFM / ASF3-32RD- (031459 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Steimel products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
