BRAND | Steimel |
Product | SF 3/40 RD-LFM |
Description | PUMP for Gear Reducer |
Internal code | 5043579 |
Custom code | 84136039 |
Technical specification | Article number: ASF3-40 Dimensional Drawing: DPA053D-201379R Spare part list: DET053040 Suction and pressure connection: SAE 1 ½ Housing parts: EN-GJL-250 (GG-25) Sprocket shafts: 16MnCrS5, egh., oblique warp. Shaft sealing: radial shaft seal Elastomers: NBR Storage: multi-layer MD Pumping medium: lubricating oil Viscosity: 50 - 5000 cSt. Temperature: 10 - 60°C Flow rate: approx. 60 1/min. Pressure: 3 - 4 bar Speed: 1450 rpm Pressure relief valve opening pressure: 4.5 bar Direction of rotation: right Test run: yes, with HLPD 46 pump support/foot (IJN250): BLF053250128-01, with Intermediate sheet for mounting dimensions, according to the above dimensional drawing Coupling: BKUA055-1928-301 Three-phase motor: LDX100-04-030 (HEW) Power: 3.0 kW Speed: 1500 rpm Voltage: 230/400 volts Frequency: 50 Hz Efficiency class: IE3 Protection class: IP 55 Insulation class: F Ignition protection type: Ex db eb IIC T4 Gb Design: B 5 Coating: RAL7030 (HDE7030, stone grey) Identification plate: ETY924-D-E--PE02 Pump unit not in accordance with EU Directive 2014/34/EU (ATEX)! |
Discover the superior quality and performance of the Steimel SF 3/40 RD-LFM with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The SF 3/40 RD-LFM is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of SF 3/40 RD-LFM :
At RADWARD LTD , we offer the SF 3/40 RD-LFM at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the SF 3/40 RD-LFM ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Steimel products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
