| BRAND | Steimel |
| Product | PSF3/50RD-113568R // SF 3/50 RD - LF |
| Description | gear pump |
| Internal code | 4650828 |
| Technical specification | P-SF3/50RD-LF, gear pump, 2-18 bar FKM, suitable for NEMA 215TD (similar to B5) Siemens AG Material number: 000.001.542.313 Gear pump: SF 3/50 RD - LF Product no.: PSF3/50RD-113568R Dimension sheet: DPP053D-133631R Spare parts list: DET053050RD-165R Suction and pressure connection: SAE 1 1/2 Case parts: EN-GJL-250 (GG-25) Pinion shafts, noise opti.: 16MnCrS5, egh. oblique distortion Storage: Multi-layer MD Shaft seal: radial shaft seal Elastomers: FKM Pumped medium: lubricating oil Viscosity: 50-5000 cSt Flow rate: approx. 55 l/min pressure: 5 bar Speed: 1140 rpm pressure relief valve Setting range: 2-18 bar Opening pressure: 8 bar direction of rotation: right Test run: yes, with HLPD 46 Clutch: BKUA065-1934-302 Pump mount with foot: BLF053278165LA12 suitable for three-phase motor: NEMA 215 TD (5 HP 1200 RPM) Design: D-flange (similar to B5) paint: without Identification plate: ETY924-D/E—PE01 Motor mounting screws: 4 pieces IBO1/2X31, loose in pump carrier screwed in |
Discover the superior quality and performance of the Steimel PSF3/50RD-113568R // SF 3/50 RD - LF with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The PSF3/50RD-113568R // SF 3/50 RD - LF is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of PSF3/50RD-113568R // SF 3/50 RD - LF :
At RADWARD LTD , we offer the PSF3/50RD-113568R // SF 3/50 RD - LF at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the PSF3/50RD-113568R // SF 3/50 RD - LF ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Steimel products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
A-SF4 / 80RD-VLFM, pump unit, 2-16 bar, 5.5 kW, 1500, 400 / 690V, 50Hz, IP55, Iso.F, IE2, material number: 000,001,152,831, gear pump unit: SF 4/80 RD - VLFM Article no. : ASF4 / 80RD-111959R Dimension sheet: DPA054D-132LFM-R31 Spare Parts List: DET054080RD - 165 Suction and. Pressure connection: SAE 2 Housing parts: EN-GJL-250 (GG-25) Waves: 16 Mn Cr 5 S, egh. Gears: EN-GJS-400-15 (GGG-40) ionitriert, with helical teeth Gearing: noise-optimized Storage: multilayer MD Shaft seal: radial shaft seal Elastomers: FKM Medium: Oil Viscosity: 50-5000 cSt. Temperature: 10-60 ° C
BMS 2-36 RD (Art.Nr.BZP042V36RD-0001R)
Gear pump
PUMP,OIL,MOTORIZED,GEAR TYPE480V 60HZ .55KW
gear pump
Gear pump
gear pump
Gear pump FKM, noise-optimised
BZP053050RD-R DMB053D-01R SF 3/50 RD
Gear pump
SF4 / 80RD-O, gear pump, FKM, 2-16 bar, noise-optimized, molded-in valve, gear pump: SF 4/80 RD - O Article no. : BZP054080RD - 165R Dimension sheet: DMB054D-01R Spare Parts List: DET054080RD - 165R Suction and. Pressure connection: SAE 2 Housing parts: EN-GJL-250 (GG-25) Waves: 16MnCrS5, egh. Gears, noise opti. : EN-GJS-400-15 (GGG-40) ionitriert, with helical teeth Storage: multilayer MD Shaft seal: radial shaft seal Elastomers: FKM Medium: Oil Viscosity: 50-5000 cSt. Temperature: 10-60 ° C Flow rate: about 104.7 l / min. Pressure: 5 bar Rotational speed 1450 1 / min, pressure relief valve opening pressure. 8 bar Setting range: 2-16 bar Rotation: r c e n t s Test run: yes, with HLPD 46 Painting: Primed (HDO058) Nameplate: ETY924 D / E - PE01
gear pump
Pinion
pinion
Bearing bush 22x25x25 multilayer (DU)
Valve Feder 4,00x16x100 A4 SF 3: 2-18 bar
Shuttle SF 3, A4 42CrMo4V (1.7225) conical seat from damage protect!
F5958 , SIZE : 4 , ( SF 2/20 RD - VLFM )
Gear Pump
Gear pump
pump
radial shaft seal BABSL
O-Ring 70/80 Grad Shore 38x2 mm Viton
O-Ring 70/80 Grad Shore 90x2 mm Viton
Collet spring steel, H 12.5 / 10,6x13,5
AC motor
AC motor
Drehstrommotor
AC motor 090-04, IE2 B5 1.5 kW, 1500, 230 / 400V, 50Hz, IP55, Iso.F Nameplate stamping IE2: - 230/400 volt 50 Hz - 1.5 kW - 265/460 volt 60 Hz - 1.7 kW Engine with additional rating plate without CE and IE2 marking: - 220-240 / 380-420 volts at 50/60 Hz - 250-280 / 440-480 volts at 60 Hz
AC motor
