| BRAND | Sanyo Denki |
| Product | San Ace 120 Model S109S078UL |
| Description | Fan |
| Internal code | 657883 |
| Weight | 1 |
| Technical specification | Model No.: 109S074UL Frame size [mm]: 120 Frame thickness [mm]: 38 Frame material: Aluminum Rated voltage [V]: 115 Operating voltage range [V]: 103.5～126.5 Frequency [Hz]: 50/60 Locked rotor current [A]: 0.27/0.24 Rated current [A]: 0.21/0.18 Rated input [W]: 18/16 Rated speed [min-1]: 2700/3100 Max. airflow [m3/min]: 2.5/2.9 Max. airflow [CFM]: 88.3/102.5 Max. static pressure [Pa]: 57.9/68.7 Max. static pressure[inchH2O]: 0.233/0.276 SPL [dB(A)]: 42/45 Operating temperature[˚C]: -30～+60 Expected life[h]: 25000/60℃ （56000/40℃） Mass [g]: 550 PWM control function: No Ribbed: No |
Discover the superior quality and performance of the Sanyo Denki San Ace 120 Model S109S078UL with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The San Ace 120 Model S109S078UL is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of San Ace 120 Model S109S078UL :
At RADWARD LTD , we offer the San Ace 120 Model S109S078UL at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the San Ace 120 Model S109S078UL ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Sanyo Denki products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
