BRAND | Tapflo |
Product | T100PEU-2S5TS7HN |
Description | compressed air diaphragm pump |
Internal code | 4814220 |
Custom code | 84135080 |
Technical specification | Tapflo® compressed air diaphragm pump Type T100PEU-2S5TS7HN stainless steel valve seats Technical description: Max. flow rate 125 l/min (with water) Maximum delivery pressure 8 bar with 8 bar compressed air Suction height dry/filled 3.5 mWs/9 mWs Maximum solid size 6 mm Max. temperature range -20ºC... +70°C Middle block PP, solid (not in contact with the product) Polyethylene housing parts in contact with the product, solid AISI 316 L stainless steel valve seats EPDM membranes PUR valve balls Suction and pressure connection G 1" internal thread (DN 25) EPDM seals Brass/PET control valve, NBR Weight 12 kg For air consumption, see delivery curve Box contents: pump including muffler and rubber feet |
Discover the superior quality and performance of the Tapflo T100PEU-2S5TS7HN with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The T100PEU-2S5TS7HN is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of T100PEU-2S5TS7HN :
At RADWARD LTD , we offer the T100PEU-2S5TS7HN at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the T100PEU-2S5TS7HN ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Tapflo products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
