| BRAND | Georgin |
| Product | P/N:0PC06BPSYB0A0; Type:C6PX |
| Description | Temperature switch |
| Internal code | 4162819 |
| Custom code | 90321080 |
| Technical specification | Capillary tube temperature switch 3 m Capillary tube temperature switches of the P series Degree of protection: IP66 Housing: mazak, epoxy coated, stainless steel screws Measuring range: 25°C... 95°C max. temperature: 105°C Sensor element: 3 m capillary/bulb d: 14 x 150mm Material: 316L st. st. Capillary tube protection: st. st. armor 1 (dry) SPDT contact adjustable hysteresis (low/high): 4... 25°C/2... 9°C Current: 5 A/240 VAC - 0.5 A/110 VDC Cable gland: polyamide M20 (d:7.5-13mm) Special feature: St. St. Tag Plate PED information: Material match with PED 2014/68/EU category IV |
Discover the superior quality and performance of the Georgin P/N:0PC06BPSYB0A0; Type:C6PX with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The P/N:0PC06BPSYB0A0; Type:C6PX is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of P/N:0PC06BPSYB0A0; Type:C6PX :
At RADWARD LTD , we offer the P/N:0PC06BPSYB0A0; Type:C6PX at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the P/N:0PC06BPSYB0A0; Type:C6PX ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Georgin products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Ref. FP6PX 1 296,00 296,00 Pressure switch F series protection : IP66 housing : mazak, epoxy painted-st.st. screws range : 0.5 to 10 bar max. pressure : 15 bar sensing element : bellows material : 316L st. st. process connection : 1/2"GM switch : 1 tropicalized SPDT adjust. deadband : <0,24 to 2 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10)
Pressure switch F series protection : IP66 housing : mazak, epoxy painted range : 5 to 50 bar max. pressure : 80 bar sensing element : bellows material : 316L st. st. process connection : 1/2"NPTM switch : 1 tropicalized SPDT adjust. deadband : <1,4 to 10 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10)
Pressure switch F series protection : IP66 housing : mazak, epoxy painted range : 25 to 400 bar max. pressure : 600 bar sensing element : Bourdon tube material : 316Ti st. st. process connection : 1/2"NPTM switch : 1 tropicalized SPDT adjust. deadband : <32 to 200 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10)
(Pressure switch F series protection: IP66 housing: mazak, epoxy painted range: 2.5 to 25 bar max. pressure : 30 bar sensing element : bellows material: 316L st. st. process connection : 1/2"NPTM switch: 2 separate tropicalized SPDT adj. from : <0,6 to 5 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10) )
Diff.pressure switch P series protection : IP66 housing : mazak, epoxy painted range : 2 to 40 mbar max. static pressure : 3 bar sensing element : diaphragm BunaN material : BunaN - mazak flange process connection : 1/4"NPTF switch : 1 SPDT, dry contact adjust. deadband : <11 to 30 mbar current rating : 5A/240VAC - 0.5A/110VDC cable gland : polyamid M20 (Ø7.5-13)
Intrinsically Safe Control
Insulator 230V AC, input/output 4-20mA
Zener Barriere
Zener diode
range: 115-210 °C sensing element: 2 m capillary- bulb 9 mm diameter, 120 mm length, copper
Capillary temperature switch F series protection : IP66 / ATEX flame proof housing : Ex-proof in epoxy painted-st.st. screws range : -20 to +45 ºC max. temperature : 55 ºC sensing element : 4m capillary-bulb Ø14x150mmmaterial : 316Ti st. st. capillary protection : st. st. armor switch : 1 tropicalized SPDT adjust. deadband :(low/high of range)4-20ºC/1-7ºC current rating : 10A/240VAC - 0.5A/110VDC cable gland : as option (elect. connect. 3/4"NPTF) features: Ex d st. st. tag plate
Capillary temperature switch F series protection : IP66 / ATEX flame proof housing : Ex-proof in epoxy painted-st.st. screws range : 20 to 95 ºC max. temperature : 105 ºC sensing element : 4m capillary-bulb Ø14x150mm material : 316Ti st. st. capillary protection : st. st. armor switch : 1 tropicalized SPDT adjust. deadband :(low/high of range)5-25ºC/1-8ºC current rating : 10A/240VAC - 0.5A/110VDC cable gland : as option (elect. connect. 3/4"NPTF) features: Ex d st. st. tag plate
Pressure switch F series protection : IP66 / ATEX intrinsic safety housing : mazak, epoxy painted range : 5 to 50 bar max. pressure : 80 bar sensing element : bellows material : 316L st. st.
Pressure switch F series
Pressure switch
Pressure switch F series
(Gauge pressure transmitter... GR/GA series housting: stainless steel / protection: IP65 range : 0...50 bar maxi pressure : 150 bar sensor: ceramic cell on viton gasket process connection : 1/2" BSPM - st.st. 316 L electrical connector : DIN43650 power supply : 10...30Vdc output signal : 4...20 mA max. global error : 0.5% FS --------ATEX information------------ EC type examination certificate LCIE 01 ATEX 6137X Ex ia IIC T6 or T5 Ga (-30 Ta 55 or 70Celsius) Ex ia IIIC T80Celsius or T95Celsius Da (-30 Ta 55 Celsius or 70 Celsius Groupe II - category 1GD - Zones 0-1-2 or 20-21-2: Ex ia I - group I (MInes) -CAtegory Mi Production Notification LCIE 02 ATEX Q 8023 See leaflet for a safe use)
Drucktransmitter
Drucktransmitter
Drucktransmitter
SWITCH PRESSURE
(Pressure switch)
pressure Switch
(Pressure switch P series protection : IP66 housing : mazak, epoxy painted-st.st. screws range : 10 to 90 bar max. pressure : 250 bar sensing element : bellows material : 316L st. st. process connection : 1/2"NPTM switch : 2 simultaneous SPDT, dry contact adjust. deadband current rating : 5A/240VAC - 0.5A/110VDC cable gland : polyamid M20 (Ø7.5-13) features: st. st. tag plate)
material : PBT Goods of French / E.U. origin European Customs Tariff Pressure Switch : 9032 2000
Druckschalter mit Flansch
