BRAND | BFI AUTOMATION |
Product | 6013-2031-00 ( Type: CFC2000UV ) |
Description | Compact Flame Controller |
Internal code | 3846247 |
Custom code | 84169000 |
Technical specification | Compact Flame Controller CFC2000UV relay and 0/4-20mA output Dual channel compact system for continuous monitoring of gas and oil burners of any power with additional frequency analysis for a better selectivity. The compact flame controller is equipped with a semiconductor sensor whose spectral sensitivity lies in the UV range. A electronic self-monitoring ensures safe operation. Flame intensity as well as the flame replay status is indicated via LEDs. Safety switch-off time can be predefined via jumper and set by software ( 1-5s ). Sensitivity, switch ON/OFF level and switch ON delay are controlled by software. Online frequency analysing and visualisation of flame radiation is possible with the BFI software Two separate and adjustable sensitivity levels Floating change-over contact for the signal flame ON/OFF Glame relay: potential-free change-over contacts , max. 48V swotching voltage max. 1A switching current max. 30W switching power Flame signal output: 0/4-20mA ( Ra<250 Ohm ) Spectral range: 2 280 to 420nm Operating mode: continuous operation Viewing angle: 2.7 C Self checking: once per 800ms Supply voltage: 24V DC Current consumption: approx. 200mA Ambient temperature: -20 to +70C Data transfer via: RS232/Infrared Interface Electrical connection: Harting-plug 90 Dimensions(mm.) L235 x W108 x H190 Housing: Aluminium, RAL5010,IP65 ATEX-zone: II 3G Ex ec nC II T4 Gc SIL: SIL3 |
Discover the superior quality and performance of the BFI AUTOMATION 6013-2031-00 ( Type: CFC2000UV ) with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 6013-2031-00 ( Type: CFC2000UV ) is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 6013-2031-00 ( Type: CFC2000UV ) :
At RADWARD LTD , we offer the 6013-2031-00 ( Type: CFC2000UV ) at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the 6013-2031-00 ( Type: CFC2000UV ) ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply BFI AUTOMATION products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
