BRAND | Orbinox |
Product | Type VGV |
Description | Knifegatevalve |
Internal code | 4288352 |
Technical specification | with elastomer sleeves Flanges acc. to ANSI B 16.5 (class 150) Diameter : DN 450 / 18" Body : Cast iron GJS 400, Epoxy coated RAL 5015 Slide : Stainless steel AISI 316 (1.4401) Stem : Stainless Steel AISI 430 (1.4016) , rising Yoke : A570 GR40 (1.0044), epoxy coated RAL 5015 Gland follower : A570 GR40 (1.0044), epoxy coated RAL 5015 Packing : EPDM Sleeves : Natural Rubber Actuator : Handwheel (≥ DN 250 with gear and handwheel) Max. pressure : DN 50 – 400 = 10 bar, DN 450 – 600 = 6 bar, DN 700 – 900 = 5 bar Accessories : --- without Fixing material |
Discover the superior quality and performance of the Orbinox Type VGV with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The Type VGV is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of Type VGV :
At RADWARD LTD , we offer the Type VGV at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the Type VGV ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Orbinox products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
