Buy VIP-363-HOA from Alerton in United Kingdom

BRAND	Alerton
Product	VIP-363-HOA
Internal code	4495005
Technical specification	POWER - 20 to 30 VAC @ 50-60 Hz. 50 VA minimum 650.00 € 650.00 € (maximum 100 VA across all BO loads). Half-wave rectified. 03 INPUTS - 16-bit universal inputs accept 10k thermistor (type II and III), dry contact, 1k platinum RTD, 0-20 mA, 0-10 V, or dry-contact pulse. External resistor required for 0-20 mA. Pulse input maximum frequency of 100 Hz. Pulse input minimum duty cycle 5ms ON / 5ms OFF. POWER OUTPUT FOR EXTERNAL SENSORS - 20 VDC ±10% @ 250 MA maximum. 06 BINARY OUTPUTS - Solid-state relay rated 20-30 VAC @ 50/60 Hz, 1.0 amp continuous, 3.5 amp inrush for 100ms. Hand-Off-Auto (H-O-A) switches for manual override, software controlled, monitored switch position status. See IMPORTANT NOTE below. 03 ANALOG OUTPUTS - 16-bit universal analog outputs support Voltage Mode: 0-10 VDC @ 10 mA maximum (1k ohm minimum); Current Mode: 4-20 mA @ 550 ohms Maximum; or Binary Mode: 12 VDC @ 20mA maximum relay coil current (for controlling lowcoil current 12 VDC relays and solid-state relays). Hand- Off-Auto (H-O-A) switches with potentiometers for manual override, software controlled, monitored switch position and potentiometer status. MICROSET - Supports BACtalk® Microset, Microset II, or Microset 4 on input 0 (IN-0). INPUT/OUTPUT TERMINATIONS - Removable header-type screw terminals. PRESSURE SENSOR (VIP-363-VAV) - 16-bit polarity insensitive pressure sensor. 0-2 in.w.c. (500 Pa) range. 0.0004 in.w.c. (0.1 Pa) zero-point accuracy. 0.5% span repeatability. 1/8-inch x 3/8-inch long barb-fitting. Field replaceable. MAX DIMENSIONS - 5.32“ (135 mm) W x 4.33” (110 mm) H x 2.26” (57.4 mm) D. MOUNTING - 35mm DIN rail or screw mounting. ENVIRONMENTAL - Ambient: -20 to 55°C (-4 to 131°F) / Storage: -20 to 85°C (-4 to 185°F) / 5 to 95%RH noncondensing. COMMUNICATIONS - Built-in 4-port Gigabit Ethernet Switch supports 10/100/1000BASE-T. PROTOCOLS - BACnet/Ethernet, BACnet/IPv4, BACnet/IPv6, and Rapid Spanning Tree Protocol (RSTP). PROGRAMMING - Supports Alerton’s BD9 DDC file format using Alerton’s VisualLogic® toolset. REAL TIME CLOCK - 24-hour, 365-day, multi-year calendar, with 24-hour power fail backup. AUTOMATION FEATURES - Supports 100 trendlogs, 100 alarms, 10 schedules, and 1 zone (internal points only) MICROPROCESSOR - 32-bit ARM Cortex-A9, 800 MHz. MEMORY - 1GB LPDDR3 RAM and 2GB solid-state disk storage. I/O MICROCONTROLLER - 32-bit ARM Cortex-M4F, 180 MHz. SECURITY - Integrated secure boot prevents loading of tampered firmware. INPUT/OUTPUT EXPANSION - VIP-363-HOA model supports up to a maximum of eight expansion I/O modules VXIO-322-HOA and VXIO-965-HOA. Expansion I/O modules connect directly to VIP-363- HOA or can be remotely located up to 3000 feet away from the VIP-363-HOA. VIP-363-VAV does not support the VXIO modules.

Discover the superior quality and performance of the Alerton VIP-363-HOA with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The VIP-363-HOA is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of VIP-363-HOA :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At RADWARD LTD , we offer the VIP-363-HOA at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose RADWARD LTD ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the VIP-363-HOA ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Alerton products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
