| BRAND | Brusatori |
| Product | VT090P4P00062 |
| Internal code | 4692113 |
| Technical specification | B-VT90P-3-4P-2/4/50*28/250+VF602048LD VT090P4PXX2F2G2XXD3XD4XXXAVBB Asynchronous vector motor type VT 90 P, power 3 Kw, 4 poles, flange D 250 mm, centering 180mm, hole spacing 215 mm, construction form IMB5, shaft 28x60 mm, top base, with SICK VFS60 2048 pr encoder, Line Driver (TTL), with fan single-phase axial 220 V - IP23, with temperature protector normally closed 140 °C, voltage 230/400V - 50 Hz, IP54 PROTECTION. |
Discover the superior quality and performance of the Brusatori VT090P4P00062 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The VT090P4P00062 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of VT090P4P00062 :
At RADWARD LTD , we offer the VT090P4P00062 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the VT090P4P00062 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Brusatori products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Motor
Servomotor 247.71 247.71 Type: MP 21 Rated speed: 3000 rpm Armature voltage: 24 V Shaft: 9 x 20 mm Flange: B14 / 56 Weight: 2.7 kg Mattke Product Code: MIMP21-024V
DC Motor
DC Motor type ML112M Kw.22,6 rpm 3000 V.440/330, mounting form B35, shaft 32x80mm, completed of forced fan, thermal protection, and tachopredisposition.
Speed:3000 rpm Cn: 3.1 Nm In : 6.5 Amp Cp:15.5 Nm Ip :32 Amp 150Volt
MP00460000029 MP46-170/3000-19/200-B5+ATEN6X10+KALTEN
Motor MP 46, nominal torque at zero speed 4,80 Nm, speed 3000 rpm, Armature 170 V, shaft 19x40 mm, flange 200 mounting IMB5, box on top, with normal closed thermal contact, shaft for encoder 6x10 mm, with bell diameter 49 mm-lenght 46 mm.
Permanent magnet motor Nm.0,45 rpm 2000 V.48
Permanent magnet motor Nm.0,45 rpm 2000 V.48
note: BRUSATORI will be closed for holidays from 02/08/2010 until 29/08/2010
Permanent magnet motor
motor,No: 5578/01, 480W, Giri 3000, 170V, A: 3,9
motor
POWER 11 KW,SPEED 1650RPM,TORGUE 62 NM,AXİAL VENTİLATİON,FOOT MOUNTİNG,BRAKE 24 V,ENCODER 1024 PPR
BRUSH 5x6x14 DTAS10
BRUSH 5x6x14 / 15.5
Motor
Type MP 23, Cod.MP 0232603064 obsolete replaced by MPT202
Motor, Nm: 1,35,B 14 / 71 Ø 14/105,RPM : 2000 V : 48;Cn : 1,35 A In : 5,80 A;Cp : 5,9 A Ip : 25,5 A
N: 8000 min-1, D: at least 0.06 V
VI112CL-4KW-4P-50HZ-230/400-B5+VF
Asynchronous motor for inverter type VI 112 CL,
VT071L2U00059 B-VT71L-1,09-4P-4/6/87HZ-B5/14+VF601024L
Vector asynchronous motor type VT 71 L, power 1,09 Kw, 4 poles, flange D 160 mm, construction shape IMB5, shaft 14x30 mm, terminal box on the top, with encoder SICK VFS60, 1024 ppr Line Driver (TTL), with monophase fan 220 V - IP23, with normal closed thermal contact 140°, triangle connected. voltage 400/690 V - 87 Hz, IP54 PROTECTED.
Vector asynchronous motor
DYNAMO CAVA SDB60 60V. Morset + + COVER
Brush 10X7X21 / 18.5
Motor
Vector asynchronous motor
3780/2 obsolete, replaced by MPT202
Servomotor
FRENI K05 F.24 V.196 H112
