BRAND | Indexator |
Product | XR300 LS |
Internal code | 4251518 |
Technical specification | ⦁ More compact, powerful and optimally stored Rotator with slewing ring bearings ⦁ For extreme areas of application with particularly high conditions ⦁ Extremely high torques ⦁ Suitable for large dynamic loads in areas Forestry, timber handling, recycling, materials and Scrap handling ⦁ 30,000 kg max.static load, 9,000 kg max. dynamic load, 7,000 kg max radial load ⦁ Torque of 3,000 Nm at 250 bar ⦁ Oil requirement 28 l / min ⦁ Weight 77 kg ⦁ Top flange mount with threaded holes (Bolt circle 12xM20-210 mm) ⦁ Mounting below, bolt circle diameter 270 mm (8x17-270 mm) ⦁ Hydraulic connections on top 2 x 3/4 "+ 2 x 1/2" ⦁ Hydraulic connections below 2 x 3/4 " |
Discover the superior quality and performance of the Indexator XR300 LS with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The XR300 LS is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of XR300 LS :
At RADWARD LTD , we offer the XR300 LS at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the XR300 LS ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Indexator products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
