Buy ident.number: 144416 from Sauter in United Kingdom

BRAND	Sauter
Product	ident.number: 144416
Description	12-fold tool disc revolver
Internal code	4701933
Technical specification	Revolver type: 0.5.901.012 Comm. Reference: 00-11.00934/1 Identification number: 120421 SAUTER 12-fold tool disc revolver 0.5.450.412 for driven tools Motor layout: rearward according to drawing 0.5.450.412-AZ07 (095397) Right version ----------------------- standard housing Nominal height 90 mm Direction of rotation: bidirectional Turret rotary drive and tool drive with 1 AC servomotor Installation and function: according to Wiring Diagram EP-1150 SK-1487 functional diagram and HP-496 hydraulic diagram Hydraulic turret lock Operating pressure 50 bar allowable mass distortion moment: 1.25 kgm≤ Swivel drive with self-locking ‹ Overload coupling including electrical ‹ monitoring Turret and tool drive is being prepared for the cultivation of -------------------- Siemens AC servomotor: 1 FT 6 064 - 6AK7 Servo motor is used by lathe manufacturer grown. 117734 Coolant device (steel) 5 bar to max. 25 bar 1.5.450.509 Coolant injection into the tool wheel in R position 75 mm; at 345 degrees 113537 Coupling for Siemens 1FT6 064 servomotor 104997 Accessories 1.5.450.090 Revolver case mounting Standard + 5 mm 119222 Final assembly parts connection A+B and K 133518 distributor according to 0.5.450.412-AZ07 Take cable length into account in accordance with 0.5.450,412 AZ01 Coupling for tool drive in position 3 a.m. distributor is attached by the machine manufacturer, therefore with cable ties on the ring bolt attach!! 133958 Sliding coupling 1.5.450.016 for revised tool drive with m=1.05 for tool wheel SW 220/D 25 mm Coupling profile in accordance with DIN 5480-W14 x 0.8 x 30 x 16 Performance data on the tool coupling Power = 20 Nm Power = 6 kW at 25% duty cycle - 10 min nzul = 6000 rpm at 25% ED - 10 min Drive motor in tool operation must be limited to these values 120421 SAUTER 12-fold tool disc 0.5.901.012/450.4 to accommodate tool holders after DIN 69 880 T1 in a radial arrangement Wrench size 220 mm Mounting holes for shaft diameter 25 mm Right version with Emco alignment system Position number sequence left-wise 1,2,... No. 1 at 3:00 Coolant supply in position R 75 mm; 345 degrees Brushed surface including clamping elements 147868 Locking plate SW 220 (without rotary distributor) 121930 Final assembly parts

Discover the superior quality and performance of the Sauter ident.number: 144416 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The ident.number: 144416 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of ident.number: 144416 :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At RADWARD LTD , we offer the ident.number: 144416 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose RADWARD LTD ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the ident.number: 144416 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Sauter products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
